Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 30, 2019, 05:10 AM

  • 11_1_1_29052019_222838.mp4

Date
05/29/2019
W/O
766493
Weather
Dry
Operator/Surveyor
J. BUENROSTRO
Sewer ID
Z00228
PipeID
P01805
Time
10:10 PM
Certificate
U-715-07000770
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K6555
Sewer Name
01 WRIGHT ROAD TRUNK
City
BELL
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
05
Purpose
Routine Assessment
Project
WO_766493_TV01251_MAY2019
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Width
24 in.
Upstream MH
01 0968
Downstream MH
01 0967
Dir. of Survey
Downstream
Length Surveyed
350.9 ft.
Total Length
350.9 ft.
Structural Index
3
Structural Quick
413M
Structural Rating
212
O&M Index
2
O&M Quick
2Y00
O&M Rating
256
Overall Index
2
Overall Quick
—
Overall Rating
468
Pipe schematic from manhole 01 0968 to 01 0967
MH: 01 0968MH: 01 0967downstream0 ft. MWL - Water Level, 25 %of cross sectional area0 ft. MWM - Water Mark, 35 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01 09686.5 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start6.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start30.2 ft. FS - Fracture Spiral, from 11 to 01 o'clock, within 8 inches of joint: YES, Start30.2 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish57.8 ft. DSC - Deposits Settled Compacted, 10 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start76.6 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: NO168.5 ft. DAR - Deposits Attached Ragging, 5 %of cross sectional area, at 12 o'clock, , within 8 inches of joint: YES172.9 ft. FM - Fracture Multiple, from 11 to 12 o'clock, within 8 inches of joint: NO313.8 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES347.7 ft. FS - Fracture Spiral, from 11 to 01 o'clock, within 8 inches of joint: YES, Finish349.7 ft. DSC - Deposits Settled Compacted, 10 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish349.7 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish350.9 ft. AMH - Downstream Manhole, Survey Ends - 01 0967

Observation photos (5)

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start

    6.5 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    6.5 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Deposits Attached Ragging, 5 %of cross sectional area, at 12 o'clock, , within 8 inches of joint: YES

    168.5 ft. - Deposits Attached Ragging, 5 %of cross sectional area, at 12 o'clock, , within 8 inches of joint: YES

  • Fracture Multiple, from 11 to 12 o'clock, within 8 inches of joint: NO

    172.9 ft. - Fracture Multiple, from 11 to 12 o'clock, within 8 inches of joint: NO

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    313.8 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

All inspections of P01805Work order 766493

Observations (16)

DistanceCodeObservation
6.5FL—
350.9AMH01 0967
76.6CL—
313.8CL—
168.5DAR—
0MWL—
0MWM—
349.7DSC—
347.7FS—
349.7DAGS—
57.8DSC—
30.2FS—
172.9FM—
0AMH01 0968
30.2FL—
6.5DAGS—

Properties (7)

additional_info
SC377677
custom_field_two
2
customer
LACSD
datetime
2019-05-29T22:10:38-07:00
documentation
PROPIPE
is_lateral_inspection
false
year_laid
10286
