Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 19, 2019, 06:10 AM

  • 9_1_1_19062019_001024.mp4

Date
06/18/2019
W/O
766407
Weather
Dry
Operator/Surveyor
J. BUENROSTRO
Sewer ID
Z00349
PipeID
P02970
Time
11:10 PM
Certificate
U-715-07000770
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K6570
Sewer Name
02 DISTRICT #2 INTERCEPTOR TRUNK
City
BELL GARDENS
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
23
Purpose
Routine Assessment
Project
WO_766407_TV02220_MAY2019
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
48 in.
Width
48 in.
Upstream MH
02 1399
Downstream MH
02 1398
Dir. of Survey
Downstream
Length Surveyed
950.3 ft.
Total Length
950.3 ft.
Structural Index
4
Structural Quick
5e3e
Structural Rating
1512
O&M Index
1
O&M Quick
2114
O&M Rating
6
Overall Index
4
Overall Quick
—
Overall Rating
1518
Pipe schematic from manhole 02 1399 to 02 1398
MH: 02 1399MH: 02 1398downstream0 ft. MWL - Water Level, 25 %of cross sectional area0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 02 13996.5 ft. SRV - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start6.5 ft. MGO - General Observation - MAG COAT THROUGHOUT PIPE6.5 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start6.6 ft. LR - Alignment Right, 10 %, Start24.5 ft. LR - Alignment Right, 10 %, Finish752.8 ft. TBC - Tap Break-In Capped, at 02 o'clock, -, within 8 inches of joint: NO, 8"943.6 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: NO, 6"950.3 ft. SRV - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish950.3 ft. AMH - Downstream Manhole, Survey Ends - 02 1398950.3 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

Observation photos (2)

  • Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    6.5 ft. - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    6.5 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P02970Work order 766407

Observations (13)

DistanceCodeObservation
24.5LR—
0MWL—
6.5SRV—
6.5MGOMAG COAT THROUGHOUT PIPE
0MWM—
950.3SRV—
943.6TB—
752.8TBC—
6.6LR—
0AMH02 1399
950.3AMH02 1398
950.3SAP—
6.5SAP—

Properties (6)

additional_info
SC377695
custom_field_two
2
customer
LACSD
datetime
2019-06-18T23:10:36-07:00
documentation
PROPIPE
is_lateral_inspection
false
