Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 19, 2016, 05:35 AM

  • 03 0381_03 0380_20160518_224836.mp4

Date
05/18/2016
W/O
557879
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00381
PipeID
P04950
Time
10:35 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3381
Sewer Name
03 MARINA RELIEF TRUNK, SECTION 1B
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
24
Purpose
Routine Assessment
Project
WO_557879_TV03013_MARCH2016
Sewer Type
GRAVITY
Material
Vitrified Clay Pipe
Lining Method
Segmented Panel
Shape
Circular
Height
21 in.
Upstream MH
03 0381
Downstream MH
03 0380
Dir. of Survey
Downstream
Length Surveyed
423.4 ft.
Total Length
423.4 ft.
Structural Index
3
Structural Quick
3422
Structural Rating
16
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
16
Pipe schematic from manhole 03 0381 to 03 0380
MH: 03 0381MH: 03 0380downstream0 ft. MGO - General Observation - CONNECTION AT MH 3 OCLOCK0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. MGO - General Observation - CONNECTION AT MH 9 OCLOCK0 ft. AMH - Upstream Manhole, Survey Begins - 03 038133.3 ft. CL - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES49.3 ft. CL - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES76 ft. TF - Tap Factory Made, at 09 o'clock, -, within 8 inches of joint: NO, 6"145.1 ft. CM - Crack Multiple, from 07 to 09 o'clock, within 8 inches of joint: YES151.7 ft. CM - Crack Multiple, from 07 to 09 o'clock, within 8 inches of joint: YES169.6 ft. CM - Crack Multiple, from 12 to 03 o'clock, within 8 inches of joint: YES175.2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start417.9 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish423.4 ft. AMH - Downstream Manhole, Survey Ends - 03 0380

Observation photos (6)

  • Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

    33.3 ft. - Crack Longitudinal, at 04 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES

    49.3 ft. - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 07 to 09 o'clock, within 8 inches of joint: YES

    145.1 ft. - Crack Multiple, from 07 to 09 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 07 to 09 o'clock, within 8 inches of joint: YES

    151.7 ft. - Crack Multiple, from 07 to 09 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 12 to 03 o'clock, within 8 inches of joint: YES

    169.6 ft. - Crack Multiple, from 12 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    175.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P04950Work order 557879

Observations (14)

DistanceCodeObservation
0MGOCONNECTION AT MH 3 OCLOCK
175.2CM—
0MWL—
76TF—
49.3CL—
169.6CM—
0MWM—
0MGOCONNECTION AT MH 9 OCLOCK
0AMH03 0381
423.4AMH03 0380
33.3CL—
151.7CM—
417.9CM—
145.1CM—

Properties (6)

additional_info
SC300380
custom_field_two
3
customer
LACSD
datetime
2016-05-18T22:35:57-07:00
documentation
PROPIPE
is_lateral_inspection
false
