Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 6, 2018, 10:32 AM

  • B 0454_B 0453 _06062018_034319.mp4

Date
06/06/2018
W/O
706794
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00093
PipeID
P08966
Time
3:32 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5689
Sewer Name
B JOINT OUTFALL B - UNIT 5C
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
11
Purpose
Routine Assessment
Project
WO_706794_TV16033_JUN2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
21 in.
Width
21 in.
Upstream MH
B 0454
Downstream MH
B 0453
Dir. of Survey
Downstream
Length Surveyed
376 ft.
Total Length
376 ft.
Structural Index
3
Structural Quick
3N00
Structural Rating
225
O&M Index
2
O&M Quick
2100
O&M Rating
2
Overall Index
3
Overall Quick
—
Overall Rating
227
Pipe schematic from manhole B 0454 to B 0453
MH: B 0454MH: B 0453downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - B 04540 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. MWM - Water Mark, 25 %of cross sectional area3.2 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start3.2 ft. MGO - General Observation - MAG COAT278.2 ft. RFB - Roots Fine Barrell, at 10 o'clock376 ft. AMH - Downstream Manhole, Survey Ends - B 0453376 ft. MGO - General Observation - CONNECTION AT MH 12 O'CLOCK376 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish376 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK

Observation photos (2)

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    3.2 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Roots Fine Barrell, at 10 o'clock

    278.2 ft. - Roots Fine Barrell, at 10 o'clock

All inspections of P08966Work order 706794

Observations (11)

DistanceCodeObservation
278.2RFB—
376AMHB 0453
0MWL—
0AMHB 0454
376MGOCONNECTION AT MH 12 O'CLOCK
0MGOCONNECTION AT MH 9 O'CLOCK
376SAV—
0MWM—
3.2SAV—
3.2MGOMAG COAT
376MGOCONNECTION AT MH 9 O'CLOCK

Properties (6)

additional_info
SC359348
custom_field_two
3
customer
LACSD
datetime
2018-06-06T03:32:10-07:00
documentation
PROPIPE
is_lateral_inspection
false
