Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Feb 8, 2016, 11:06 AM

  • 05 0096_05 0095_20160208_032225.mp4

Date
02/08/2016
W/O
541742
Weather
Dry
Operator/Surveyor
J. HARTOOG
Sewer ID
Z00431
PipeID
P05386
Time
3:06 AM
Certificate
U-507-03-3386
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K3138
Sewer Name
05 DISTRICT #5 MAIN TRUNK
City
HAWTHORNE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
17
Purpose
Routine Assessment
Project
WO_541742_TV05147_DEC2015
Material
Reinforced Concrete Pipe
Shape
Circular
Height
42 in.
Upstream MH
05 0096
Downstream MH
05 0095
Dir. of Survey
Downstream
Length Surveyed
332.4 ft.
Total Length
332.4 ft.
Structural Index
1
Structural Quick
1L00
Structural Rating
64
O&M Index
2
O&M Quick
2L00
O&M Rating
128
Overall Index
2
Overall Quick
—
Overall Rating
192
Pipe schematic from manhole 05 0096 to 05 0095
MH: 05 0096MH: 05 0095downstream0 ft. AMH - Upstream Manhole, Survey Begins - 05 00960 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MGO - General Observation - LATERAL AT MH 9 OCLOCK0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MGO - General Observation - LATERAL AT MH 3 OCLOCK2 ft. MGO - General Observation - MAGNESIUM H.O. START7.8 ft. SRI - Surface Roughness Increased, from 09 to 03 o'clock, within 8 inches of joint: YES, Start7.8 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start328.4 ft. SRI - Surface Roughness Increased, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish328.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish332.3 ft. MGO - General Observation - LATERAL AT MH 9 OCLOCK332.4 ft. AMH - Downstream Manhole, Survey Ends - 05 0095

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    7.8 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Surface Roughness Increased, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish

    328.4 ft. - Surface Roughness Increased, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish

All inspections of P05386Work order 541742

Observations (12)

DistanceCodeObservation
2MGOMAGNESIUM H.O. START
0AMH05 0096
7.8SRI—
332.4AMH05 0095
328.4SRI—
0MWM—
328.4DAGS—
7.8DAGS—
0MGOLATERAL AT MH 9 OCLOCK
0MWL—
332.3MGOLATERAL AT MH 9 OCLOCK
0MGOLATERAL AT MH 3 OCLOCK

Properties (6)

additional_info
SC225525
custom_field_two
4
customer
LACSD
datetime
2016-02-08T03:06:00-08:00
documentation
PROPIPE
is_lateral_inspection
false
