Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 9, 2015, 12:00 PM

  • 16 0605_16 0604_20151209_041924.mp4

Date
12/09/2015
W/O
531059
Weather
Dry
Operator/Surveyor
R.VARGAS
Sewer ID
Z00664
PipeID
P13655
Time
4:00 AM
Certificate
U-209-211
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K2843
Sewer Name
16 PASADENA EAST-WEST INTERCEPTOR TRUNK
City
PASADEMA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
10
Purpose
Routine Assessment
Project
WO_531059_TV16030_OCT2015
Sewer Type
GRAVITY
Material
Reinforced Concrete Pipe
Shape
Circular
Height
39 in.
Upstream MH
16 0605
Downstream MH
16 0604
Dir. of Survey
Downstream
Length Surveyed
411.4 ft.
Total Length
411.4 ft.
Structural Index
3
Structural Quick
3O00
Structural Rating
243
O&M Index
2
O&M Quick
2O12
O&M Rating
164
Overall Index
2
Overall Quick
—
Overall Rating
407
Pipe schematic from manhole 16 0605 to 16 0604
MH: 16 0605MH: 16 0604downstream0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. VC - Vermin Cockroach0 ft. MGO - General Observation - LATERAL AT MH 9 OCLOCK ACTIVE0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 16 06052.1 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start2.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start2.2 ft. MGO - General Observation - MAGNEZIUM H.O. START141.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6"189.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6"230.7 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"278.2 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6"295.5 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"330.3 ft. VC - Vermin Cockroach373.1 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"409.1 ft. MGO - General Observation - MAGNEZIUM H.O. FINISH409.2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish409.2 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish411.4 ft. MGO - General Observation - AIR VENT AT MH411.4 ft. AMH - Downstream Manhole, Survey Ends - 16 0604411.4 ft. MGO - General Observation - LATERAL AT MH 9 OCLOCK ACTIVE

Observation photos (2)

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2.1 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • General Observation - MAGNEZIUM H.O. START

    2.2 ft. - General Observation - MAGNEZIUM H.O. START

All inspections of P13655Work order 531059

Observations (21)

DistanceCodeObservation
141.7TFC—
411.4MGOAIR VENT AT MH
330.3VC—
295.5TFA—
409.2DAGS—
0MWM—
278.2TFC—
411.4AMH16 0604
409.2SAV—
409.1MGOMAGNEZIUM H.O. FINISH
189.3TFC—
411.4MGOLATERAL AT MH 9 OCLOCK ACTIVE
0VC—
2.1SAV—
373.1TFA—
2.2MGOMAGNEZIUM H.O. START
0MGOLATERAL AT MH 9 OCLOCK ACTIVE
230.7TFA—
0MWL—
2.1DAGS—
0AMH16 0605

Properties (6)

additional_info
SC205697
custom_field_two
3
customer
LACSD
datetime
2015-12-09T04:00:23-08:00
documentation
PRO PIPE
is_lateral_inspection
false
