Wastewater/Activity/PacpInspection/1.0Oct 20, 2016, 08:06 AM
05 1063_05 1062 _20102016_010733.mp4
- Date
- 10/20/2016
- W/O
- 591782
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00488
- PipeID
- P06297
- Time
- 1:06 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3811
- Sewer Name
- 05 MONETA EXTENSION TRUNK, SECTION 1
- City
- GARDENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 21
- Purpose
- Routine Assessment
- Project
- WO_591782_TV05306_SEP2016
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 24 in.
- Width
- 24 in.
- Upstream MH
- 05 1063
- Downstream MH
- 05 1062
- Dir. of Survey
- Downstream
- Length Surveyed
- 288.7 ft.
- Total Length
- 288.7 ft.
- Structural Index
- 3
- Structural Quick
- 3300
- Structural Rating
- 9
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 9
Observation photos (3)
12.8 ft. - Crack Multiple, from 07 to 03 o'clock, within 8 inches of joint: YES
70 ft. - Crack Multiple, from 08 to 11 o'clock, within 8 inches of joint: YES
109.2 ft. - Crack Multiple, from 07 to 10 o'clock, within 8 inches of joint: YES
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWM | — |
| 281 | TF | — |
| 86.3 | TFA | — |
| 70 | CM | — |
| 109.2 | CM | — |
| 12.8 | CM | — |
| 0 | AMH | 05 1063 |
| 288.7 | AMH | 05 1062 |
| 185.6 | TFA | — |
| 0 | MWL | — |
Properties (6)
- additional_info
- SC304556
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-10-20T01:06:04-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
