Wastewater/Activity/PacpInspection/1.0Jul 29, 2016, 05:44 AM
02 0788B_02 0788A_20160728_234927.mp4
- Date
- 07/28/2016
- W/O
- 574316
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00294
- PipeID
- P18785
- Time
- 10:44 PM
- Certificate
- U-507-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3666
- Sewer Name
- 02 OLD RIVER SCHOOL ROAD TRUNK, SECTS 1&2
- City
- DOWNEY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 24
- Purpose
- Routine Assessment
- Project
- WO_574316_TV02111_JUNE2016
- Sewer Type
- Siphon
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 02 0788B
- Downstream MH
- 02 0788A
- Dir. of Survey
- Downstream
- Length Surveyed
- 2 ft.
- Total Length
- 2 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 4
- O&M Quick
- 5131
- O&M Rating
- 8
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (3)
2 ft. - Survey Abandoned - DUE TO SIPHON
2 ft. - General Observation - VIEW OF THE DOWLEG OF THE UPSTREAM MH
2 ft. - Deposits Attached Grease, 15 %of cross sectional area, from 01 to 11 o'clock, , within 8 inches of joint: YES
Observations (6)
| Distance | Code | Observation |
|---|---|---|
| 0 | AMH | 02 0788B |
| 2 | MSA | DUE TO SIPHON |
| 0 | MWM | — |
| 0 | MWL | — |
| 2 | MGO | VIEW OF THE DOWLEG OF THE UPSTREAM MH |
| 2 | DAGS | — |
Properties (6)
- additional_info
- SC305545
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-07-28T22:44:00-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
