Wastewater/Activity/PacpInspection/1.0Oct 17, 2017, 06:24 AM
H 0401A_H 0401_16102017_232452.mp4
- Date
- 10/16/2017
- W/O
- 646746
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00177
- PipeID
- P10831
- Time
- 11:24 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5024
- Sewer Name
- H JOINT OUTFALL H - UNIT 5A
- City
- CITY OF INDUSTRY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 01
- Purpose
- Routine Assessment
- Project
- WO_646746_TV15130_JUL2017
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 60 in.
- Width
- 60 in.
- Upstream MH
- H 0401A
- Downstream MH
- H 0401
- Dir. of Survey
- Downstream
- Length Surveyed
- 472.5 ft.
- Total Length
- 472.5 ft.
- Structural Index
- 4
- Structural Quick
- 5R3Q
- Structural Rating
- 741
- O&M Index
- 4
- O&M Quick
- 4100
- O&M Rating
- 4
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 745
Observation photos (2)
10.4 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
11.5 ft. - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 10.4 | SAP | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 0 | MWL | — |
| 0 | MWM | — |
| 11.5 | SRV | — |
| 0 | AMH | H 0401A |
| 472.4 | SRV | — |
| 165 | SRV | — |
| 472.2 | SAP | — |
| 472.5 | AMH | H 0401 |
Properties (5)
- additional_info
- SC346184
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-10-16T23:24:18-07:00
- is_lateral_inspection
- false
