Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 10, 2019, 05:03 PM

  • H 0487_H 0486_7102019_103331.mp4

Date
07/10/2019
W/O
0771738
Weather
Dry
Operator/Surveyor
BRAR
Sewer ID
Z00181
PipeID
P10913
Time
10:03 AM
Certificate
0618-0703002249
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G 8023
Sewer Name
H JOINT OUTFALL H - UNIT 6
City
INDUSTRY
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
29
Purpose
Routine Assessment
Project
20190710SB_H_JOINT_OUTFALL_H_UNIT_6
Material
Reinforced Concrete Pipe
Shape
Circular
Height
54 in.
Upstream MH
H 0487
Downstream MH
H 0486
Dir. of Survey
Downstream
Length Surveyed
469 ft.
Total Length
469 ft.
Structural Index
4
Structural Quick
5131
Structural Rating
8
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
4
Overall Quick
—
Overall Rating
8
Pipe schematic from manhole H 0487 to H 0486
MH: H 0487MH: H 0486downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start0 ft. SZ - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - MAG COAT 60%0 ft. SRV - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start0 ft. AMH - Upstream Manhole, Survey Begins - 10:05 AM0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. MGO - General Observation - ROACHES @ MH51.3 ft. MGP - General Photograph51.3 ft. MGP - General Photograph150.1 ft. MGP - General Photograph151.1 ft. MGP - General Photograph255.4 ft. MGP - General Photograph255.4 ft. MGP - General Photograph350.5 ft. MGP - General Photograph358.2 ft. MGP - General Photograph460.1 ft. SRV - Surface Reinforcement Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish460.1 ft. MGP - General Photograph460.1 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish460.1 ft. SZ - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - MAG COAT 60%469 ft. AMH - Downstream Manhole, Survey Ends - 10:57 AM469 ft. MGO - General Observation - GREASE THROUGHOUT REACH 4 TO 8

Observation photos (9)

  • General Photograph

    51.3 ft. - General Photograph

  • General Photograph

    51.3 ft. - General Photograph

  • General Photograph

    150.1 ft. - General Photograph

  • General Photograph

    151.1 ft. - General Photograph

  • General Photograph

    255.4 ft. - General Photograph

  • General Photograph

    255.4 ft. - General Photograph

  • General Photograph

    350.5 ft. - General Photograph

  • General Photograph

    358.2 ft. - General Photograph

  • General Photograph

    460.1 ft. - General Photograph

All inspections of P10913Work order 0771738

Observations (21)

DistanceCodeObservation
358.2MGP—
0MWL—
469AMH10:57 AM
350.5MGP—
0SAV—
460.1SRV—
0SZMAG COAT 60%
0SRV—
0AMH10:05 AM
460.1MGP—
151.1MGP—
51.3MGP—
51.3MGP—
255.4MGP—
0MWM—
0MGOROACHES @ MH
150.1MGP—
460.1SAV—
460.1SZMAG COAT 60%
469MGOGREASE THROUGHOUT REACH 4 TO 8
255.4MGP—

Properties (6)

custom_field_three
AGGREGATE VISIBLE
custom_field_two
3
customer
LACSD
datetime
2019-07-10T10:03:49-07:00
documentation
BRAR, FRANKLIN, CASTILLO
is_lateral_inspection
false
