Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 2, 2019, 09:37 AM

  • Section#4_15 0819_15 0818__722019__I0166.mp4

Date
07/02/2019
W/O
0777329
Weather
Dry
Operator/Surveyor
REVELES
Sewer ID
Z00593
PipeID
P13020
Time
2:37 AM
Certificate
U-115-06022630
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
I0166
Sewer Name
15 ARCADIA-SIERRA MADRE TRUNK, SECTS 2&5
City
SIERRA MADRE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
01
Purpose
Resurvey For Any Reason
Project
07022019VMR_ARCADIA_SIERRA_MADRE_TRUNK_SECT_2AND5
Material
NRCP
Shape
Circular
Height
9.420000076293945 in.
Upstream MH
15 0819
Downstream MH
15 0818
Dir. of Survey
Downstream
Length Surveyed
274.6 ft.
Total Length
274.6 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
1
O&M Quick
1400
O&M Rating
4
Overall Index
1
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole 15 0819 to 15 0818
MH: 15 0819MH: 15 0818downstream0 ft. AMH - Upstream Manhole, Survey Begins - 02:45 AM0 ft. MWM - Water Mark, 5 %of cross sectional area0 ft. MWL - Water Level, 20 %of cross sectional area95.5 ft. RFC - Roots Fine Connection, at 02 o'clock, within 8 inches of joint: NO139.7 ft. RFC - Roots Fine Connection, at 10 o'clock, within 8 inches of joint: NO142.2 ft. RFC - Roots Fine Connection, at 02 o'clock, within 8 inches of joint: NO243 ft. RFC - Roots Fine Connection, at 01 o'clock, within 8 inches of joint: NO274.6 ft. AMH - Downstream Manhole, Survey Ends - 3:02 AM

Observation photos (3)

  • Roots Fine Connection, at 02 o'clock, within 8 inches of joint: NO

    95.5 ft. - Roots Fine Connection, at 02 o'clock, within 8 inches of joint: NO

  • Roots Fine Connection, at 02 o'clock, within 8 inches of joint: NO

    142.2 ft. - Roots Fine Connection, at 02 o'clock, within 8 inches of joint: NO

  • Roots Fine Connection, at 01 o'clock, within 8 inches of joint: NO

    243 ft. - Roots Fine Connection, at 01 o'clock, within 8 inches of joint: NO

All inspections of P13020Work order 0777329

Observations (8)

DistanceCodeObservation
95.5RFC—
274.6AMH3:02 AM
142.2RFC—
243RFC—
0AMH02:45 AM
139.7RFC—
0MWM—
0MWL—

Properties (6)

custom_field_two
3
customer
LACSD
datetime
2019-07-02T02:37:13-07:00
documentation
REVELES, OLIVER III, SHADLER
is_lateral_inspection
false
lining
CIPP
