Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 9, 2017, 08:11 AM

  • C 0073_C 0586_992017_020035.mp4

Date
09/09/2017
W/O
0657839
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00120
PipeID
P22848
Time
1:11 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0635
Sewer Name
C JOINT OUTFALL C - UNIT 3A
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
18
Purpose
Routine Assessment
Project
20170909MDM_JOINT_OUTFALL_C_UNIT_3A
Material
Reinforced Concrete Pipe
Shape
Circular
Height
60 in.
Upstream MH
C 0073
Downstream MH
C 0586
Dir. of Survey
Downstream
Length Surveyed
70.1 ft.
Total Length
70.1 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
5
O&M Quick
5100
O&M Rating
5
Overall Index
4
Overall Quick
—
Overall Rating
8
Pipe schematic from manhole C 0073 to C 0586
MH: C 0073MH: C 0586downstream0 ft. AMH - Upstream Manhole, Survey Begins - 1:45AM0 ft. MWL - Water Level, 60 %of cross sectional area0 ft. MWM - Water Mark, 80 %of cross sectional area8 ft. MGO - General Observation - 66" RCP FR POLY LINER24.3 ft. MGP - General Photograph26.1 ft. MGO - General Observation - 60" RCP-FR-POLY-LINER64.1 ft. LFD - Lining Failure Detached, from 11 to 03 o'clock, within 8 inches of joint: NO - DOWNSTREAM SOFFIT69.5 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active70.1 ft. AMH - Downstream Manhole, Survey Ends - 2:00AM

Observation photos (3)

  • General Observation - 66" RCP FR POLY LINER

    8 ft. - General Observation - 66" RCP FR POLY LINER

  • General Photograph

    24.3 ft. - General Photograph

  • General Observation - 60" RCP-FR-POLY-LINER

    26.1 ft. - General Observation - 60" RCP-FR-POLY-LINER

All inspections of P22848Work order 0657839

Observations (9)

DistanceCodeObservation
69.5MGOConn. @ Mh, 3 O' Clock. Active
64.1LFDDOWNSTREAM SOFFIT
70.1AMH2:00AM
0AMH1:45AM
8MGO66" RCP FR POLY LINER
0MWL—
24.3MGP—
0MWM—
26.1MGO60" RCP-FR-POLY-LINER

Properties (7)

custom_field_two
4
customer
LACSD
datetime
2017-09-09T01:11:58-07:00
documentation
MARTIN,MANANES,REVELES,OLIVER 111
is_lateral_inspection
false
lining
FR POLY LINE
year_laid
19950824
