Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 21, 2016, 08:27 AM

  • G 0199_G 0198_21072016_012809.mp4

Date
07/21/2016
W/O
582914
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z01180
PipeID
P01104
Time
1:27 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3618
Sewer Name
G JOINT OUTFALL G - UNIT 8
City
LYNWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
13
Purpose
Routine Assessment
Project
WO_582914_TV01100_JULY2016
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Width
24 in.
Upstream MH
G 0198
Downstream MH
G 0199
Dir. of Survey
Upstream
Length Surveyed
290.4 ft.
Total Length
290.4 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
352K
O&M Rating
131
Overall Index
2
Overall Quick
—
Overall Rating
131
Pipe schematic from manhole G 0198 to G 0199
MH: G 0198MH: G 0199upstream0 ft. AMH - Upstream Manhole, Survey Ends - G 01990 ft. MGO - General Observation - COCKROACHES IN MANHOLE0.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish3.5 ft. DSZ - Deposits Settled Other, 15 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish28.3 ft. DSZ - Deposits Settled Other, 15 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start288.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start290.4 ft. MWL - Water Level, 25 %of cross sectional area290.4 ft. AMH - Downstream Manhole, Survey Begins - G 0198290.4 ft. MGO - General Observation - COCKROACHES IN MANHOLE290.4 ft. MWM - Water Mark, 40 %of cross sectional area290.4 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 9 O'CLOCK

Observation photos (3)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    290.4 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P01104Work order 582914

Observations (11)

DistanceCodeObservation
290.4AMHG 0199
290.4MGOCOCKROACHES IN MANHOLE
289.9DAGS—
2DAGS—
262.1DSZ—
0MWL—
0AMHG 0198
0MGOCOCKROACHES IN MANHOLE
0MWM—
0MGOACTIVE CONNECTION AT MH 9 O'CLOCK
286.9DSZ—

Properties (7)

additional_info
SC305797
custom_field_two
4
customer
LACSD
datetime
2016-07-21T01:27:49-07:00
documentation
PRO PIPE
is_lateral_inspection
false
lining
CIPP
