Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 26, 2019, 10:45 AM

  • 02 1111_02 1110_6262019_035127.mp4

Date
06/26/2019
W/O
0776968
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00285
PipeID
P03682
Time
3:45 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1247
Sewer Name
02 MONTEBELLO-RANDOLPH TRUNK
City
BELL GARDENS
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
20
Purpose
Routine Assessment
Project
20190626MDM_M0NTEBELLO_RANDOLPH_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
02 1111
Downstream MH
02 1110
Dir. of Survey
Downstream
Length Surveyed
366.7 ft.
Total Length
366.7 ft.
Structural Index
2
Structural Quick
413A
Structural Rating
134
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
2
Overall Quick
—
Overall Rating
138
Pipe schematic from manhole 02 1111 to 02 1110
MH: 02 1111MH: 02 1110downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 3:55AM6.5 ft. FC - Fracture Circumferential, from 10 to 02 o'clock, within 8 inches of joint: YES - HAIRLINE7.3 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SLIGHT FLAKING10.6 ft. FC - Fracture Circumferential, from 10 to 12 o'clock, within 8 inches of joint: YES - H18.6 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H18.6 ft. FC - Fracture Circumferential, from 08 to 11 o'clock, within 8 inches of joint: YES - H22.2 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL22.2 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - SL26.5 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H26.5 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H30.3 ft. FC - Fracture Circumferential, from 01 to 02 o'clock, within 8 inches of joint: YES - H34.4 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H34.4 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - SL38.1 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H38.1 ft. FC - Fracture Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES - H42.2 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL42.2 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL54.1 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL61.7 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL70 ft. FC - Fracture Circumferential, from 11 to 04 o'clock, within 8 inches of joint: YES - SL77.9 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - H89.9 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES - SL93.9 ft. FC - Fracture Circumferential, from 01 to 04 o'clock, within 8 inches of joint: YES - SL102.3 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL102.3 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - H109.9 ft. FC - Fracture Circumferential, from 08 to 09 o'clock, within 8 inches of joint: YES - H109.9 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL133.9 ft. FC - Fracture Circumferential, from 01 to 04 o'clock, within 8 inches of joint: YES - H149.7 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H157.8 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL169.7 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H169.7 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H177.8 ft. FC - Fracture Circumferential, from 08 to 11 o'clock, within 8 inches of joint: YES - SLIGHT186.1 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H186.1 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H201.5 ft. FC - Fracture Circumferential, from 07 to 12 o'clock, within 8 inches of joint: YES - SLIGHT209.9 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - SL221.6 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - SL221.6 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - SL229.7 ft. FC - Fracture Circumferential, from 10 to 02 o'clock, within 8 inches of joint: YES - SL229.7 ft. MWM - Water Mark, 60 %of cross sectional area253.5 ft. FC - Fracture Circumferential, from 10 to 02 o'clock, within 8 inches of joint: YES - SL261.8 ft. FC - Fracture Circumferential, from 12 to 05 o'clock, within 8 inches of joint: YES - SL273.7 ft. FC - Fracture Circumferential, from 07 to 11 o'clock, within 8 inches of joint: YES - H273.7 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL277.8 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL277.8 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL281.7 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H281.7 ft. FC - Fracture Circumferential, from 08 to 09 o'clock, within 8 inches of joint: YES - H285.7 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - H289.9 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL294 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - SL294 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H298 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL301.8 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL314.3 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL317.9 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES - SL326.5 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES - SL334.2 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H346 ft. FC - Fracture Circumferential, from 08 to 02 o'clock, within 8 inches of joint: YES - H350.4 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL362.4 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - SL362.4 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - SL366.3 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - SLIGHT FLAKING366.7 ft. AMH - Downstream Manhole, Survey Ends - 4:45AM

Observation photos (1)

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SLIGHT FLAKING

    7.3 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SLIGHT FLAKING

All inspections of P03682Work order 0776968

Observations (67)

DistanceCodeObservation
326.5FCSL
77.9FCH
0MWL—
7.3SSSSLIGHT FLAKING
334.2FLH
54.1FCSL
289.9FCSL
177.8FCSLIGHT
298FCSL
22.2FCSL
169.7FCH
89.9FMSL
186.1FLH
109.9FCH
34.4FLH
253.5FCSL
294FCSL
169.7FCH
18.6FCH
26.5FCH
350.4FCSL
362.4FLSL
314.3FCSL
34.4FLSL
346FCH
102.3FCSL
26.5FCH
229.7FCSL
42.2FCSL
186.1FLH
93.9FCSL
133.9FCH
229.7MWM—
30.3FCH
38.1FCH
317.9FCSL
102.3FCH
261.8FCSL
221.6FLSL
273.7FCH
294FCH
0MWM—
70FCSL
221.6FCSL
277.8FCSL
366.3SSSSLIGHT FLAKING
285.7FCH
201.5FCSLIGHT
0AMH3:55AM
38.1FCH
362.4FLSL
157.8FCSL
10.6FCH
209.9FLSL
301.8FCSL
109.9FCSL
22.2FCSL
6.5FCHAIRLINE
18.6FCH
281.7FCH
273.7FCSL
61.7FCSL
42.2FCSL
366.7AMH4:45AM
281.7FCH
149.7FLH
277.8FCSL

Properties (6)

custom_field_three
SLIGHT FRACTURES- SLIGHT SPALLING FLAKING
custom_field_two
3
customer
LACSD
datetime
2019-06-26T03:45:44-07:00
documentation
MARTIN,REVELES,OLIVER 111,SHADLER
is_lateral_inspection
false
