Wastewater/Activity/PacpInspection/1.0Jun 26, 2019, 07:25 AM
02 1026_02 1025_6262019_004513.mp4
- Date
- 06/26/2019
- W/O
- 0772204
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00280
- PipeID
- P03600
- Time
- 12:25 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1248
- Sewer Name
- 02 MONTEBELLO CITY TRUNK
- City
- MONTEBELLO
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 14
- Purpose
- Routine Assessment
- Project
- 20190626MDM_M0NTEBELLO_CITY_TRUNK
- Material
- NRCP
- Shape
- Circular
- Height
- 14.220000267028809 in.
- Upstream MH
- 02 1026
- Downstream MH
- 02 1025
- Dir. of Survey
- Downstream
- Length Surveyed
- 496.8 ft.
- Total Length
- 496.8 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 0
- Overall Quick
- —
- Overall Rating
- 0
Observation photos (4)
8 ft. - General Observation - 14.22" NRCP + CIPP
316.9 ft. - Lining Failure Other, from 08 to 04 o'clock, within 8 inches of joint: NO - LIGHT AREAS POSSIBLE LINER CORRISON
316.9 ft. - Lining Failure Other, from 08 to 04 o'clock, within 8 inches of joint: NO - LIGHT AREAS POSSIBLE LINER CORRISON THROUGHOUT REACH
370.8 ft. - General Observation - 14.22" NRCP + CIPP
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 370.8 | MGO | 14.22" NRCP + CIPP |
| 8 | MGO | 14.22" NRCP + CIPP |
| 496.2 | MGO | Conn. @ Mh, 12 O' Clock. Active |
| 0 | MGO | Conn. @ Mh, 9 O' Clock. STUB |
| 496.8 | AMH | 1:35AM |
| 0 | AMH | 12:45AM |
| 0 | MWM | — |
| 316.9 | LFZ | LIGHT AREAS POSSIBLE LINER CORRISON |
| 316.9 | LFZ | LIGHT AREAS POSSIBLE LINER CORRISON THROUGHOUT REACH |
| 0 | MGO | Conn. @ Mh, 3 O' Clock. Active |
| 496.2 | MGO | Conn. @ Mh, 3 O' Clock. OPEN |
| 0 | MWL | — |
Properties (7)
- custom_field_three
- POSSIBLE CORRISON PROCESS ON LINER
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-06-26T00:25:38-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,SHADLER
- is_lateral_inspection
- false
- lining
- CIPP
