Wastewater/Activity/PacpInspection/1.0Jun 25, 2019, 10:33 AM
B 1124_B 1123_6252019_033537.mp4
- Date
- 06/25/2019
- W/O
- 0771118
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z01125
- PipeID
- P13164
- Time
- 3:33 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1246
- Sewer Name
- B JOINT OUTFALL B - UNIT 6H
- City
- ALHAMBRA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 20
- Purpose
- Routine Assessment
- Project
- 20190625MDM_JOINT_OUTFALL_UNIT_6H
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 22 in.
- Upstream MH
- B 1124
- Downstream MH
- B 1123
- Dir. of Survey
- Downstream
- Length Surveyed
- 20.7 ft.
- Total Length
- 20.7 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 3
Observation photos (2)
5.9 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, - SLIGHT
15.4 ft. - Material Change, Other (state in comments) - BRICK PIPE WITH MORTAR COAT
Observations (7)
| Distance | Code | Observation |
|---|---|---|
| 15.4 | MMC | BRICK PIPE WITH MORTAR COAT |
| 0 | AMH | 3:35AM |
| 20.2 | MGO | Conn. @ Mh, 9 O' Clock. Capped-BRICK BULKHEAD |
| 0 | MWL | — |
| 20.7 | AMH | 3:45AM |
| 5.9 | FL | SLIGHT |
| 0 | MWM | — |
Properties (6)
- custom_field_three
- SLIGHT FRACTURE
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-06-25T03:33:00-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,SHADLER
- is_lateral_inspection
- false
