Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 25, 2019, 08:33 AM

  • B 1125_B 1124_6252019_021608.mp4

Date
06/25/2019
W/O
0771118
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z01125
PipeID
P13165
Time
1:33 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1246
Sewer Name
B JOINT OUTFALL B - UNIT 6H
City
ALHAMBRA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
20
Purpose
Routine Assessment
Project
20190625MDM_JOINT_OUTFALL_UNIT_6H
Material
Vitrified Clay Pipe
Shape
Circular
Height
22 in.
Upstream MH
B 1125
Downstream MH
B 1124
Dir. of Survey
Downstream
Length Surveyed
277.7 ft.
Total Length
277.7 ft.
Structural Index
2
Structural Quick
392D
Structural Rating
79
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
79
Pipe schematic from manhole B 1125 to B 1124
MH: B 1125MH: B 1124downstream0 ft. AMH - Upstream Manhole, Survey Begins - 2:35AM0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. MWM - Water Mark, 10 %of cross sectional area4 ft. FC - Fracture Circumferential, from 11 to 01 o'clock, within 8 inches of joint: YES - HAIRLINE10.6 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open12.2 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - SLIGHT20.3 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - HAIRLINE28.9 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H41.2 ft. FC - Fracture Circumferential, from 11 to 02 o'clock, within 8 inches of joint: YES - H45.7 ft. FC - Fracture Circumferential, from 12 to 02 o'clock, within 8 inches of joint: YES - H53.8 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H53.8 ft. FC - Fracture Circumferential, from 01 to 02 o'clock, within 8 inches of joint: YES - H57.9 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES - H62.2 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H62.2 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - SLIGHT62.2 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H63.4 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open65.6 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - H66.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open71.8 ft. FC - Fracture Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES - H72.4 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H75.2 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H76.8 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H76.8 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H80.8 ft. FC - Fracture Circumferential, from 10 to 03 o'clock, within 8 inches of joint: YES - H84.8 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - H94.1 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H94.1 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H98.7 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open100.1 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H100.2 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H101.8 ft. TF - Tap Factory Made, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Open103.3 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H112.9 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - H115.8 ft. FL - Fracture Longitudinal, at 08 TO 4o'clock, within 8 inches of joint: YES, Start - HAIRLINE AT JOINTS115.8 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - HAIRLINE AT JOINTS120.8 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - SL128.7 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - SL142.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open143.7 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H147.8 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - H152.3 ft. FC - Fracture Circumferential, from 08 to 01 o'clock, within 8 inches of joint: YES - SL156.2 ft. TF - Tap Factory Made, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Open158.2 ft. FC - Fracture Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES - SL162.6 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - SL175.1 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open179.3 ft. FC - Fracture Circumferential, from 11 to 01 o'clock, within 8 inches of joint: YES - SL193 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped201.5 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open208.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open222.9 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - SL233.8 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open248.5 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open260.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open277.2 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES, Finish - 10% HAIRLINE AT JOINTS277.2 ft. FC - Fracture Circumferential, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - 60% HAIRLINE AT JOINTS277.7 ft. AMH - Downstream Manhole, Survey Ends - 3:20AM

Observation photos (2)

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H

    62.2 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H

    143.7 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H

All inspections of P13165Work order 0771118

Observations (57)

DistanceCodeObservation
201.5TBOpen
71.8FCH
115.8FLHAIRLINE AT JOINTS
57.9FLH
53.8FLH
80.8FCH
94.1FCH
0AMH2:35AM
143.7FLH
76.8FCH
100.1FCH
4FCHAIRLINE
277.7AMH3:20AM
45.7FCH
156.2TFOpen
12.2FCSLIGHT
94.1FCH
277.2FL10% HAIRLINE AT JOINTS
175.1TBOpen
233.8TBOpen
62.2FLH
115.8FCHAIRLINE AT JOINTS
158.2FCSL
120.8FCSL
62.2FCSLIGHT
62.2FCH
66.4TFOpen
162.6FCSL
208.3TFOpen
277.2FC60% HAIRLINE AT JOINTS
248.5TFOpen
72.4FLH
112.9FCH
65.6FLH
0MWL—
103.3FCH
152.3FCSL
53.8FCH
20.3FCHAIRLINE
142.3TFOpen
260.2TFOpen
76.8FLH
100.2FCH
128.7FLSL
0MWM—
222.9FLSL
179.3FCSL
98.7TFOpen
101.8TFOpen
10.6TFOpen
28.9FCH
75.2FCH
63.4TFOpen
193TFCCapped
147.8FLH
84.8FCH
41.2FCH

Properties (6)

custom_field_three
HAIRLINE FRACTURES JOINT TO JOINT
custom_field_two
2
customer
LACSD
datetime
2019-06-25T01:33:58-07:00
documentation
MARTIN,REVELES,OLIVER 111,SHADLER
is_lateral_inspection
false
