Wastewater/Activity/PacpInspection/1.0Jun 24, 2019, 04:56 PM
BLANK MK_H 0714_6242019_103207.mp4
- Date
- 06/24/2019
- W/O
- 0772128
- Weather
- Dry
- Operator/Surveyor
- SANTIAGO OBREGON
- Sewer ID
- Z00941
- PipeID
- P11122
- Time
- 9:56 AM
- Certificate
- U-1014-06022541
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1245
- Sewer Name
- H JOINT OUTFALL H - UNIT 9B
- City
- BASSET
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 29
- Purpose
- Routine Assessment
- Project
- 20190624SHO_JOINT_OUTFALL_H_UNIT_9B
- Material
- NRCP
- Shape
- Circular
- Height
- 25 in.
- Upstream MH
- H 0714
- Downstream MH
- BLANK MK
- Dir. of Survey
- Upstream
- Length Surveyed
- 290.3 ft.
- Total Length
- 290.3 ft.
- Structural Index
- 3
- Structural Quick
- 3121
- Structural Rating
- 5
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 5
Observation photos (3)
20.2 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SPORADICALLY THROUGHOUT
108.9 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
230.2 ft. - Lining Change, Fold and Form or Deform/Reform - LINER IN PLACE
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 108.9 | SSS | — |
| 0 | AMH | H 714 |
| 20.2 | SAV | SPORADICALLY THROUGHOUT |
| 0 | MWM | — |
| 230.2 | MLC | LINER IN PLACE |
| 243.8 | MMC | BACK TO NRCP |
| 290.3 | MSA | AT BLANK MH, DOES NOT EXIST |
| 0 | MWL | — |
| 290.3 | SAV | — |
| 13.3 | MGO | 80% MAG COAT INTACT |
| 290.3 | SSS | — |
Properties (6)
- additional_info
- GOING U/S APPROX. 289 FEET, MH DOES NOT EXIST
- custom_field_three
- SPALLIGN AND AGG.
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2019-06-24T09:56:51-07:00
- is_lateral_inspection
- false
