Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 27, 2019, 04:25 PM

  • B 1289_B 1288_6272019_093644.mp4

Date
06/27/2019
W/O
0771792
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z01126
PipeID
P25184
Time
9:25 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G8010
Sewer Name
B JOINT OUTFALL B - UNIT 6J
City
PASADENA
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
12
Purpose
Routine Assessment
Project
20190624DF_JOINT_OUTFALL_B_UNIT_6J
Material
Vitrified Clay Pipe
Shape
Circular
Height
22 in.
Upstream MH
B 1289
Downstream MH
B 1288
Dir. of Survey
Downstream
Length Surveyed
62.3 ft.
Total Length
62.3 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole B 1289 to B 1288
MH: B 1289MH: B 1288downstream0 ft. AMH - Upstream Manhole, Survey Begins - 9:26 AM0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 20 %of cross sectional area8 ft. MGP - General Photograph22.1 ft. MGP - General Photograph40.5 ft. MGP - General Photograph62.3 ft. MGO - General Observation - Grease Throughout The Reach (5%)62.3 ft. AMH - Downstream Manhole, Survey Ends - 9:54 AM

Observation photos (4)

  • Water Level, 15 %of cross sectional area

    0 ft. - Water Level, 15 %of cross sectional area

  • General Photograph

    8 ft. - General Photograph

  • General Photograph

    22.1 ft. - General Photograph

  • General Photograph

    40.5 ft. - General Photograph

All inspections of P25184Work order 0771792

Observations (8)

DistanceCodeObservation
0AMH9:26 AM
8MGP—
22.1MGP—
0MWL—
62.3MGOGrease Throughout The Reach (5%)
40.5MGP—
0MWM—
62.3AMH9:54 AM

Properties (5)

custom_field_two
4
customer
LACSD
datetime
2019-06-27T09:25:14-07:00
documentation
FRANKLIN, BRAR, CASTILLO, RUVALCABA
is_lateral_inspection
false
