Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 24, 2019, 06:19 PM

  • B 1309_B 1308_6242019_113047.mp4

Date
06/24/2019
W/O
0771792
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z01126
PipeID
P25204
Time
11:19 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G8007
Sewer Name
B JOINT OUTFALL B - UNIT 6J
City
PASADENA
Loc. details
Woods
Location Code
E
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
12
Purpose
Routine Assessment
Project
20190624DF_JOINT_OUTFALL_B_UNIT_6J
Material
Vitrified Clay Pipe
Shape
Circular
Height
22 in.
Upstream MH
B 1309
Downstream MH
B 1308
Dir. of Survey
Downstream
Length Surveyed
117.7 ft.
Total Length
117.7 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole B 1309 to B 1308
MH: B 1309MH: B 1308downstream0 ft. AMH - Upstream Manhole, Survey Begins - 11:30 AM0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 20 %of cross sectional area23.7 ft. MGP - General Photograph76.4 ft. MGP - General Photograph83.1 ft. MGP - General Photograph117.7 ft. MGO - General Observation - Grease Throughout The Reach (5%)117.7 ft. AMH - Downstream Manhole, Survey Ends - 12:15 PM

Observation photos (4)

  • Water Mark, 20 %of cross sectional area

    0 ft. - Water Mark, 20 %of cross sectional area

  • General Photograph

    23.7 ft. - General Photograph

  • General Photograph

    76.4 ft. - General Photograph

  • General Photograph

    83.1 ft. - General Photograph

All inspections of P25204Work order 0771792

Observations (8)

DistanceCodeObservation
83.1MGP—
23.7MGP—
0AMH11:30 AM
117.7MGOGrease Throughout The Reach (5%)
0MWL—
0MWM—
76.4MGP—
117.7AMH12:15 PM

Properties (5)

custom_field_two
4
customer
LACSD
datetime
2019-06-24T11:19:55-07:00
documentation
FRANKLIN, BRAR, IGNACIO, RUVALCABA
is_lateral_inspection
false
