Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 21, 2019, 09:59 AM

  • 01 0971_01 0970_6212019_030546.mp4

Date
06/21/2019
W/O
0777634
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00228
PipeID
P01808
Time
2:59 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1241
Sewer Name
01 WRIGHT ROAD TRUNK
City
BELL
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
08
Purpose
Maintenance Related
Project
20190618MDM_WRIGHT_ROAD_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Upstream MH
01 0971
Downstream MH
01 0970
Dir. of Survey
Downstream
Length Surveyed
115 ft.
Total Length
115 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 01 0971 to 01 0970
MH: 01 0971MH: 01 0970downstream0 ft. AMH - Upstream Manhole, Survey Begins - 3:05AM0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active2 ft. MMC - Material Change, Other (state in comments) - TILE LINED PIPE88.1 ft. MMC - Material Change, Vitrified clay pipe - VCP115 ft. AMH - Downstream Manhole, Survey Ends - 3:15AM

Observation photos (2)

  • Material Change, Other (state in comments) - TILE LINED PIPE

    2 ft. - Material Change, Other (state in comments) - TILE LINED PIPE

  • Material Change, Vitrified clay pipe - VCP

    88.1 ft. - Material Change, Vitrified clay pipe - VCP

All inspections of P01808Work order 0777634

Observations (7)

DistanceCodeObservation
0AMH3:05AM
0MWL—
2MMCTILE LINED PIPE
115AMH3:15AM
88.1MMCVCP
0MWM—
0MGOConn. @ Mh, 3 O' Clock. Active

Properties (5)

additional_info
LOOKING FOR MISSING VCP
customer
LACSD
datetime
2019-06-21T02:59:24-07:00
documentation
MARTIN,REVELES,OLIVER 111,SHADLER
is_lateral_inspection
false
