Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 18, 2019, 07:49 AM

  • 01 0948_01 0947_6182019_012508.mp4

Date
06/18/2019
W/O
0777634
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00228
PipeID
P01785
Time
12:49 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1235
Sewer Name
01 WRIGHT ROAD TRUNK
City
SOUTH GATE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
08
Purpose
Maintenance Related
Project
20190618MDM_WRIGHT_ROAD_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Upstream MH
01 0948
Downstream MH
01 0947
Dir. of Survey
Downstream
Length Surveyed
291.8 ft.
Total Length
291.8 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
5
O&M Quick
5441
O&M Rating
24
Overall Index
5
Overall Quick
—
Overall Rating
24
Pipe schematic from manhole 01 0948 to 01 0947
MH: 01 0948MH: 01 0947downstream0 ft. MWM - Water Mark, 60 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:25AM0 ft. MWL - Water Level, 20 %of cross sectional area36.7 ft. MWL - Water Level, 30 %of cross sectional area154.3 ft. MWL - Water Level, 40 %of cross sectional area194.6 ft. MWM - Water Mark, 80 %of cross sectional area224.6 ft. MWM - Water Mark, 90 %of cross sectional area224.6 ft. MWL - Water Level, 50 %of cross sectional area265.4 ft. MWL - Water Level, 60 %of cross sectional area281.2 ft. MWL - Water Level, 70 %of cross sectional area291.1 ft. OBM - Obstacles Pipe Material, 70 %of cross sectional area, from 04 to 11 o'clock - VCP SECTION INSIDE MH #947291.1 ft. OBM - Obstacles Pipe Material, 70 %of cross sectional area, from 04 to 11 o'clock - VCP SECTION INSIDE MH# 947291.8 ft. AMH - Downstream Manhole, Survey Ends - 1:55AM

Observation photos (2)

  • Obstacles Pipe Material, 70 %of cross sectional area, from 04 to 11 o'clock - VCP SECTION INSIDE MH #947

    291.1 ft. - Obstacles Pipe Material, 70 %of cross sectional area, from 04 to 11 o'clock - VCP SECTION INSIDE MH #947

  • Obstacles Pipe Material, 70 %of cross sectional area, from 04 to 11 o'clock - VCP SECTION INSIDE MH# 947

    291.1 ft. - Obstacles Pipe Material, 70 %of cross sectional area, from 04 to 11 o'clock - VCP SECTION INSIDE MH# 947

All inspections of P01785Work order 0777634

Observations (13)

DistanceCodeObservation
224.6MWM—
0MWM—
281.2MWL—
265.4MWL—
0AMH1:25AM
224.6MWL—
194.6MWM—
291.1OBMVCP SECTION INSIDE MH #947
291.8AMH1:55AM
291.1OBMVCP SECTION INSIDE MH# 947
154.3MWL—
0MWL—
36.7MWL—

Properties (6)

additional_info
LOOKING FOR OBSTRUCTIONS
customer
LACSD
datetime
2019-06-18T00:49:15-07:00
documentation
MARTIN,SHADLER
is_lateral_inspection
false
year_laid
19280228
