Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 18, 2019, 12:09 PM

  • 02 1114_02 1113_6182019_051114.mp4

Date
06/18/2019
W/O
0776968
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00285
PipeID
P03685
Time
5:09 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1236
Sewer Name
02 MONTEBELLO-RANDOLPH TRUNK
City
BELL GARDENS
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
20
Purpose
Routine Assessment
Project
20190618MDM_MONTEBELLO_RANDOLPH_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
02 1114
Downstream MH
02 1113
Dir. of Survey
Downstream
Length Surveyed
378.8 ft.
Total Length
378.8 ft.
Structural Index
3
Structural Quick
463A
Structural Rating
108
O&M Index
3
O&M Quick
4121
O&M Rating
6
Overall Index
3
Overall Quick
—
Overall Rating
114
Pipe schematic from manhole 02 1114 to 02 1113
MH: 02 1114MH: 02 1113downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 5:10AM6.2 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SLIGHT6.2 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start10.1 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - SL26.3 ft. FC - Fracture Circumferential, from 10 to 02 o'clock, within 8 inches of joint: YES - HAIRLINE34.5 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - SL38.2 ft. FC - Fracture Circumferential, from 09 to 01 o'clock, within 8 inches of joint: YES - H46.8 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H58.1 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H62.2 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - H70.1 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL78 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H78 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H86.1 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - SL94 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL102.2 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL110.1 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - H118.2 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - H118.2 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL130.2 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - SL134 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H137.9 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL141.9 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - H146.3 ft. FC - Fracture Circumferential, from 11 to 03 o'clock, within 8 inches of joint: YES - SL149.9 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - H165.9 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H174.3 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H177.9 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - H182 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - SL197.6 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H205.7 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - SL213.6 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - SL233.6 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H249.4 ft. FC - Fracture Circumferential, from 08 to 09 o'clock, within 8 inches of joint: YES - H249.4 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL265.4 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL277.4 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H285.1 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H309.2 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - SL313.2 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL321.3 ft. FC - Fracture Circumferential, from 02 to 03 o'clock, within 8 inches of joint: YES - H345.2 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H361.5 ft. FC - Fracture Circumferential, from 10 to 03 o'clock, within 8 inches of joint: YES - SL369 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL378.2 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish378.8 ft. AMH - Downstream Manhole, Survey Ends - 5:44AM

Observation photos (1)

  • Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    6.2 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

All inspections of P03685Work order 0776968

Observations (48)

DistanceCodeObservation
70.1FCSL
130.2FMSL
345.2FLH
58.1FLH
378.2DAGS—
86.1FMSL
233.6FLH
78FLH
378.8AMH5:44AM
94FCSL
182FMSL
165.9FLH
213.6FMSL
62.2FCH
149.9FCH
26.3FCHAIRLINE
265.4FCSL
369FCSL
309.2FCSL
174.3FLH
10.1FMSL
6.2FCSLIGHT
313.2FCSL
102.2FCSL
34.5FCSL
197.6FLH
321.3FCH
0MWL—
0MWM—
285.1FLH
277.4FLH
361.5FCSL
177.9FCH
118.2FCH
249.4FCH
137.9FCSL
249.4FCSL
38.2FCH
78FLH
118.2FCSL
46.8FLH
0AMH5:10AM
110.1FCH
141.9FCH
205.7FMSL
146.3FCSL
134FLH
6.2DAGS—

Properties (6)

custom_field_three
SLIGHT FRACTURES
custom_field_two
3
customer
LACSD
datetime
2019-06-18T05:09:14-07:00
documentation
MARTIN,SHADLER
is_lateral_inspection
false
