Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 18, 2019, 11:08 AM

  • 02 1115_02 1114_6182019_041703.mp4

Date
06/18/2019
W/O
0776968
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00285
PipeID
P03686
Time
4:08 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1236
Sewer Name
02 MONTEBELLO-RANDOLPH TRUNK
City
BELL GARDENS
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
20
Purpose
Routine Assessment
Project
20190618MDM_MONTEBELLO_RANDOLPH_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
02 1115
Downstream MH
02 1114
Dir. of Survey
Downstream
Length Surveyed
239.8 ft.
Total Length
239.8 ft.
Structural Index
2
Structural Quick
4139
Structural Rating
69
O&M Index
3
O&M Quick
4121
O&M Rating
6
Overall Index
2
Overall Quick
—
Overall Rating
75
Pipe schematic from manhole 02 1115 to 02 1114
MH: 02 1115MH: 02 1114downstream0 ft. AMH - Upstream Manhole, Survey Begins - 4:15AM0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active10.5 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - HAIRLINE14.5 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - H26.4 ft. FC - Fracture Circumferential, from 08 to 10 o'clock, within 8 inches of joint: YES - H30.2 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H33.9 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H33.9 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H38.3 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H46.1 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - SLIGHT46.1 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES - H50.1 ft. FL - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES - H50.1 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H62.2 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - H66.4 ft. FC - Fracture Circumferential, from 12 to 02 o'clock, within 8 inches of joint: YES - H70.4 ft. FL - Fracture Longitudinal, at 09 TO 3o'clock, within 8 inches of joint: YES, Start - HAIRLINE AT JOINTS70.4 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - HAIRLINE AT JOINTS78.4 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - SL90.3 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start94.6 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL106.6 ft. MWM - Water Mark, 30 %of cross sectional area118.8 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL138.8 ft. FC - Fracture Circumferential, from 08 to 11 o'clock, within 8 inches of joint: YES - SL150.7 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL154.9 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - SL177.4 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - SL183 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - SL187.3 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES - SL203.2 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - SL215.1 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SL227.1 ft. FC - Fracture Circumferential, from 08 to 11 o'clock, within 8 inches of joint: YES - SL234.9 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SL234.9 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - SL239.2 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish239.2 ft. FC - Fracture Circumferential, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish - 60% HAIRLINE AT JOINTS239.2 ft. FL - Fracture Longitudinal, at 09 TO 3 o'clock, within 8 inches of joint: YES, Finish - 30% HAIRLINE AT JONTS239.8 ft. AMH - Downstream Manhole, Survey Ends - 5:00AM

Observation photos (1)

  • Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    90.3 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

All inspections of P03686Work order 0776968

Observations (39)

DistanceCodeObservation
215.1FLSL
14.5FLH
183FCSL
46.1FCSLIGHT
0AMH4:15AM
38.3FCH
46.1FLH
118.8FCSL
177.4FCSL
239.8AMH5:00AM
227.1FCSL
78.4FCSL
30.2FLH
138.8FCSL
0MWM—
239.2DAGS—
239.2FC60% HAIRLINE AT JOINTS
26.4FCH
33.9FLH
10.5FCHAIRLINE
66.4FCH
203.2FLSL
187.3FCSL
90.3DAGS—
94.6FCSL
150.7FCSL
50.1FLH
50.1FCH
62.2FMH
106.6MWM—
70.4FLHAIRLINE AT JOINTS
154.9FCSL
239.2FL30% HAIRLINE AT JONTS
0MWL—
70.4FCHAIRLINE AT JOINTS
234.9FCSL
33.9FLH
234.9FCSL
0MGOConn. @ Mh, 9 O' Clock. Active

Properties (6)

custom_field_three
SLIGHT FRACTURES
custom_field_two
3
customer
LACSD
datetime
2019-06-18T04:08:08-07:00
documentation
MARTIN,SHADLER
is_lateral_inspection
false
