Wastewater/Activity/PacpInspection/1.0Jun 20, 2019, 05:20 PM
H 0903_H 0820_6202019_104733.mp4
- Date
- 06/20/2019
- W/O
- 0771771
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00934
- PipeID
- P20375
- Time
- 10:20 AM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G8004
- Sewer Name
- H JOINT OUTFALL H - UNIT 5A RELIEF
- City
- WHITTIER
- Loc. details
- Other
- Location Code
- Z
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 33
- Purpose
- Routine Assessment
- Project
- 20190618DF_JOINT_OUTFALL_H_UNIT_5A_RELIEF
- Material
- RCP-PTL
- Shape
- Circular
- Height
- 84 in.
- Upstream MH
- H 0820
- Downstream MH
- H 0819
- Dir. of Survey
- Downstream
- Length Surveyed
- 576.6 ft.
- Total Length
- 576.6 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 0
- Overall Quick
- —
- Overall Rating
- 0
Observation photos (6)
0 ft. - Water Mark, 20 %of cross sectional area
129.1 ft. - General Photograph
230 ft. - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: YES, 4"
309.1 ft. - General Photograph
512.8 ft. - General Photograph
575.8 ft. - General Photograph
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 576.6 | AMH | 11:11 AM |
| 512.8 | MGP | — |
| 575.8 | MGP | — |
| 309.1 | MGP | — |
| 0 | MWL | — |
| 0 | AMH | 10:30 AM |
| 129.1 | MGP | — |
| 230 | TFA | — |
| 0 | MWM | — |
| 576.6 | MGO | GREASE THROUGHOUT THE REACH (5%) |
Properties (6)
- additional_info
- ONSCREEN REACH IS WRONG. CORRECT MH'S ARE U/S H 0820 TO D/S H 0819. TAPE NUMBER SHOULD BE (G8004)
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-06-20T10:20:47-07:00
- documentation
- FRANKLIN, BRAR, IGNACIO, RUVALCABA
- is_lateral_inspection
- false
