Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 14, 2019, 06:36 PM

  • B 1323_B 1322_6142019_113843.mp4

Date
06/14/2019
W/O
0771792
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z01126
PipeID
P25218
Time
11:36 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G8000
Sewer Name
B JOINT OUTFALL B - UNIT 6J
City
PASADENA
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
12
Purpose
Routine Assessment
Project
20190614DF_JOINT_OUTFALL_B_UNIT_6J
Material
Vitrified Clay Pipe
Shape
Circular
Height
22 in.
Upstream MH
B 1323
Downstream MH
B 1322
Dir. of Survey
Downstream
Length Surveyed
100.5 ft.
Total Length
100.5 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
4
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole B 1323 to B 1322
MH: B 1323MH: B 1322downstream0 ft. AMH - Upstream Manhole, Survey Begins - 11:38 AM0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. MWL - Water Level, 15 %of cross sectional area32.8 ft. MWL - Water Level, 65 %of cross sectional area32.8 ft. MWM - Water Mark, 70 %of cross sectional area50.6 ft. MGP - General Photograph57.9 ft. MWM - Water Mark, 20 %of cross sectional area57.9 ft. MWL - Water Level, 15 %of cross sectional area100.5 ft. AMH - Downstream Manhole, Survey Ends - 11:47 AM100.5 ft. MGO - General Observation - GREASE THROUGHOUT THE REACH (5%)

Observation photos (4)

  • Upstream Manhole, Survey Begins - 11:38 AM

    0 ft. - Upstream Manhole, Survey Begins - 11:38 AM

  • Water Level, 65 %of cross sectional area

    32.8 ft. - Water Level, 65 %of cross sectional area

  • General Photograph

    50.6 ft. - General Photograph

  • Water Level, 15 %of cross sectional area

    57.9 ft. - Water Level, 15 %of cross sectional area

All inspections of P25218Work order 0771792

Observations (10)

DistanceCodeObservation
57.9MWM—
0AMH11:38 AM
100.5AMH11:47 AM
32.8MWL—
50.6MGP—
57.9MWL—
0MWM—
32.8MWM—
100.5MGOGREASE THROUGHOUT THE REACH (5%)
0MWL—

Properties (5)

custom_field_two
4
customer
LACSD
datetime
2019-06-14T11:36:59-07:00
documentation
FRANKLIN, BRAR, CASTILLO, RUVALCABA
is_lateral_inspection
false
