Wastewater/Activity/PacpInspection/1.0Aug 23, 2017, 09:30 AM
29 0377_29 0376 _23082017_025008.mp4
- Date
- 08/23/2017
- W/O
- 651742
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00537
- PipeID
- P24414
- Time
- 2:30 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4791
- Sewer Name
- 29 21ST STREET SEWER
- City
- SIGNAL HILL
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 29
- Page No.
- 04
- Purpose
- Routine Assessment
- Project
- WO_651742_TV29055_AUG2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 29 0377
- Downstream MH
- 29 0376
- Dir. of Survey
- Downstream
- Length Surveyed
- 331.9 ft.
- Total Length
- 331.9 ft.
- Structural Index
- 3
- Structural Quick
- 3L23
- Structural Rating
- 201
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 201
Observation photos (4)
4.6 ft. - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start
63.7 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES
141.5 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES
274.8 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES
Observations (16)
| Distance | Code | Observation |
|---|---|---|
| 331.9 | SAV | — |
| 4.6 | SAV | — |
| 141.5 | CL | — |
| 274.8 | CL | — |
| 4.6 | MMC | — |
| 150.5 | TF | — |
| 244.3 | TF | — |
| 63.7 | CL | — |
| 39 | TF | — |
| 0 | AMH | 29 0377 |
| 252.6 | TF | — |
| 140.3 | TF | — |
| 331.9 | AMH | 29 0376 |
| 0 | MWM | — |
| 0 | MWL | — |
| 0 | MGO | CONNECTION AT MH 3 O'CLOCK |
Properties (5)
- additional_info
- SC345550
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-08-23T02:30:30-07:00
- is_lateral_inspection
- false
