Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 3, 2017, 05:29 AM

  • 03 0044_03 0043_02082017_224013.mp4

Date
08/02/2017
W/O
646910
Weather
Dry
Operator/Surveyor
B. FUGATE
Sewer ID
Z00366
PipeID
P05064
Time
10:29 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4769
Sewer Name
03 LOS COYOTES DIAGONAL TRUNK
City
LAKEWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
09
Purpose
Routine Assessment
Project
WO_646534_TV03011_JUL2017
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
03 0044
Downstream MH
03 0043
Dir. of Survey
Downstream
Length Surveyed
341.5 ft.
Total Length
341.5 ft.
Structural Index
1
Structural Quick
1200
Structural Rating
2
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
1
Overall Quick
—
Overall Rating
2
Pipe schematic from manhole 03 0044 to 03 0043
MH: 03 0044MH: 03 0043downstream0 ft. AMH - Upstream Manhole, Survey Begins - 03 00440 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 20 %of cross sectional area60.8 ft. CC - Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES83.7 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"140.6 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"143.9 ft. CC - Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES182.2 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"234.1 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"268.9 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"331.1 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"341.5 ft. AMH - Downstream Manhole, Survey Ends - 03 0043

Observation photos (8)

  • Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES

    60.8 ft. - Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES

  • Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    83.7 ft. - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

  • Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    140.6 ft. - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

  • Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES

    143.9 ft. - Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES

  • Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    182.2 ft. - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

  • Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    234.1 ft. - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

  • Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    268.9 ft. - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

  • Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

    331.1 ft. - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"

All inspections of P05064Work order 646910

Observations (14)

DistanceCodeObservation
0AMH03 0044
0MGOCONNECTION AT MH 3 O'CLOCK
0MGOCONNECTION AT MH 9 O'CLOCK
182.2TS—
331.1TS—
341.5AMH03 0043
60.8CC—
143.9CC—
234.1TS—
83.7TS—
268.9TS—
0MWL—
140.6TS—
0MWM—

Properties (6)

additional_info
SC345529
custom_field_two
4
customer
LACSD
datetime
2017-08-02T22:29:19-07:00
documentation
PRO PIPE
is_lateral_inspection
false
