Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 11, 2017, 11:30 AM

  • 02 1700_02 2156_01112017_033109.mp4

Date
01/11/2017
W/O
613349
Weather
Light Rain
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00289
PipeID
P18859
Time
3:30 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4207
Sewer Name
02 MONTEREY PARK EXTENSION TRUNK
City
MONTEREY PARK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
06
Purpose
Routine Assessment
Project
WO_613349_TV02103_JAN2017
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
02 1700
Downstream MH
02 2156
Dir. of Survey
Downstream
Length Surveyed
143.1 ft.
Total Length
143.1 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
2E00
O&M Rating
56
Overall Index
2
Overall Quick
—
Overall Rating
56
Pipe schematic from manhole 02 1700 to 02 2156
MH: 02 1700MH: 02 2156downstream0 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 3 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Begins - 02 17000 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MGO - General Observation - COCKROACHES IN MANHOLE2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start38.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"59 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"107.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"118.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"125.9 ft. TBA - Tap Break-In Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"141.6 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish141.6 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 10 O'CLOCK143.1 ft. MGO - General Observation - COCKROACHES IN MANHOLE143.1 ft. AMH - Downstream Manhole, Survey Ends - 02 2156

Observation photos (3)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    143.1 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P18859Work order 613349

Observations (15)

DistanceCodeObservation
143.1MGOCOCKROACHES IN MANHOLE
38.9TFC—
141.6DAGS—
59TFC—
0MGOACTIVE CONNECTION AT MH 3 O'CLOCK
2DAGS—
107.1TFC—
118.1TFC—
0AMH02 1700
125.9TBA—
0MWM—
143.1AMH02 2156
0MWL—
0MGOCOCKROACHES IN MANHOLE
141.6MGOACTIVE CONNECTION AT MH 10 O'CLOCK

Properties (6)

additional_info
SC306709
custom_field_two
4
customer
LACSD
datetime
2017-01-11T03:30:49-08:00
documentation
PRO PIPE
is_lateral_inspection
false
