Wastewater/Activity/PacpInspection/1.0Apr 20, 2017, 06:02 AM
15 0528_15 0527 _19042017_230418.mp4
- Date
- 04/19/2017
- W/O
- 630147
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00629
- PipeID
- P12456
- Time
- 11:02 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4471
- Sewer Name
- 15 SANTA ANITA OUTFALL TRUNK
- City
- EL MONTE
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 16
- Purpose
- Routine Assessment
- Project
- WO_630147_TV15085_APR2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 15 0527
- Downstream MH
- 15 0528
- Dir. of Survey
- Upstream
- Length Surveyed
- 505.8 ft.
- Total Length
- 505.8 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2Q00
- O&M Rating
- 184
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 184
Observation photos (1)
46.3 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 08 to 04 o'clock, , within 8 inches of joint: YES, Start
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 505.6 | DAE | — |
| 0 | MWL | — |
| 505.6 | MGO | CONNECTION AT MH 12 O'CLOCK |
| 0 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 505.6 | MGO | CONNECTION AT MH 9 O'CLOCK |
| 505.8 | AMH | 15 0528 |
| 46.3 | DAE | — |
| 0 | MWM | — |
| 325.7 | TB | — |
| 20.7 | TB | — |
| 205.6 | TBA | — |
| 0 | AMH | 15 0527 |
Properties (5)
- additional_info
- SC345180
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2017-04-19T23:02:11-07:00
- is_lateral_inspection
- false
