Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 11, 2018, 05:13 AM

  • 29 0005_29 0004 _10052018_222331.mp4

Date
05/10/2018
W/O
701392
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00849
PipeID
P17679
Time
10:13 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5665
Sewer Name
29 SIGNAL HILL OUTFALL TRUNK
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
19
Purpose
Routine Assessment
Project
WO_701392_TV29096_MAY2018
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Width
24 in.
Upstream MH
29 0005
Downstream MH
29 0004
Dir. of Survey
Downstream
Length Surveyed
91.1 ft.
Total Length
91.1 ft.
Structural Index
4
Structural Quick
563B
Structural Rating
81
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
4
Overall Quick
—
Overall Rating
81
Pipe schematic from manhole 29 0005 to 29 0004
MH: 29 0005MH: 29 0004downstream0 ft. AMH - Upstream Manhole, Survey Begins - 29 00050 ft. MGO - General Observation - HEAVY STEAM0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MGO - General Observation - INFILTRATION IN MH2.1 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start8.6 ft. IS - Infiltration Stain, from 08 to 11 o'clock, within 8 inches of joint: YES17.1 ft. IS - Infiltration Stain, from 08 to 04 o'clock, within 8 inches of joint: YES, Start60.1 ft. SRV - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start88.5 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish88.5 ft. SRV - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish88.5 ft. IS - Infiltration Stain, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish91 ft. MGO - General Observation - INFILTRATION IN MH91.1 ft. AMH - Downstream Manhole, Survey Ends - 29 0004

Observation photos (5)

  • General Observation - INFILTRATION IN MH

    0 ft. - General Observation - INFILTRATION IN MH

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2.1 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Infiltration Stain, from 08 to 11 o'clock, within 8 inches of joint: YES

    8.6 ft. - Infiltration Stain, from 08 to 11 o'clock, within 8 inches of joint: YES

  • Infiltration Stain, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    17.1 ft. - Infiltration Stain, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    60.1 ft. - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

All inspections of P17679Work order 701392

Observations (14)

DistanceCodeObservation
0AMH29 0005
0MGOHEAVY STEAM
88.5SAP—
88.5SRV—
91.1AMH29 0004
2.1SAP—
8.6IS—
0MWM—
17.1IS—
0MWL—
88.5IS—
0MGOINFILTRATION IN MH
60.1SRV—
91MGOINFILTRATION IN MH

Properties (5)

additional_info
SC359322
custom_field_two
2
customer
LACSD
datetime
2018-05-10T22:13:08-07:00
is_lateral_inspection
false
