Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Apr 4, 2018, 08:37 AM

  • B 0450_B 0449 _04042018_013839.mp4

Date
04/04/2018
W/O
698202
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00093
PipeID
P08962
Time
1:37 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5517
Sewer Name
B JOINT OUTFALL B - UNIT 5C
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
11
Purpose
Routine Assessment
Project
WO_698202_DISTRICT16_APR2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
21 in.
Width
21 in.
Upstream MH
B 0450
Downstream MH
B 0449
Dir. of Survey
Downstream
Length Surveyed
229.7 ft.
Total Length
229.7 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
1
O&M Quick
1200
O&M Rating
2
Overall Index
2
Overall Quick
—
Overall Rating
5
Pipe schematic from manhole B 0450 to B 0449
MH: B 0450MH: B 0449downstream0 ft. MWM - Water Mark, 35 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - B 04500 ft. MWL - Water Level, 15 %of cross sectional area3.7 ft. MGO - General Observation - MAG COAT3.7 ft. SAV - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start17.7 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"59.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"62.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"121.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"124.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"155.8 ft. RFJ - Roots Fine Joint, at 04 o'clock, within 8 inches of joint: YESR184 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"187.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"187.3 ft. RFL - Roots Fine Lateral, at 02 o'clock229.6 ft. SAV - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Finish229.7 ft. MGO - General Observation - SERVICE CONNECTION AT 9 O'CLOCK AT MH229.7 ft. AMH - Downstream Manhole, Survey Ends - B 0449

Observation photos (2)

  • Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start

    3.7 ft. - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start

  • Roots Fine Joint, at 04 o'clock, within 8 inches of joint: YESR

    155.8 ft. - Roots Fine Joint, at 04 o'clock, within 8 inches of joint: YESR

All inspections of P08962Work order 698202

Observations (17)

DistanceCodeObservation
3.7MGOMAG COAT
0MWM—
229.7MGOSERVICE CONNECTION AT 9 O'CLOCK AT MH
187.3TF—
0AMHB 0450
229.7AMHB 0449
121.8TF—
124.4TFC—
0MWL—
62.1TF—
187.3RFL—
17.7TF—
155.8RFJ—
59.1TFC—
3.7SAV—
184TFC—
229.6SAV—

Properties (6)

additional_info
SC358724
custom_field_two
3
customer
LACSD
datetime
2018-04-04T01:37:25-07:00
documentation
PROPIPE
is_lateral_inspection
false
