Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 12, 2019, 10:59 AM

  • J 0492_J 0491_6122019_040123.mp4

Date
06/12/2019
W/O
0756080
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00057
PipeID
P24757
Time
3:59 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1231
Sewer Name
J JOINT OUTFALL J - UNIT 1E
City
PALO VERDES
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
47
Purpose
Routine Assessment
Project
20190612MDM_JOINT_OUTFALL_J_UNIT_1E
Material
RGRCP
Shape
Circular
Height
48 in.
Upstream MH
J 0492
Downstream MH
J 0491
Dir. of Survey
Downstream
Length Surveyed
506.9 ft.
Total Length
506.9 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole J 0492 to J 0491
MH: J 0492MH: J 0491downstream0 ft. AMH - Upstream Manhole, Survey Begins - 4:15AM0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area2 ft. MGO - General Observation - OLD MAG COAT ON PIPE12.7 ft. MGP - General Photograph - OLD MAG COAT243.7 ft. MGO - General Observation - RGRCP GOOD COND506.7 ft. MGO - General Observation - JOINTS IN PLACE THROUGHOUT REACH506.9 ft. AMH - Downstream Manhole, Survey Ends(ABANDON4ED MH) - 4:55AM( ABANDONED MH)

Observation photos (4)

  • General Observation - OLD MAG COAT ON PIPE

    2 ft. - General Observation - OLD MAG COAT ON PIPE

  • General Photograph - OLD MAG COAT

    12.7 ft. - General Photograph - OLD MAG COAT

  • General Observation - RGRCP GOOD COND

    243.7 ft. - General Observation - RGRCP GOOD COND

  • General Observation - JOINTS IN PLACE THROUGHOUT REACH

    506.7 ft. - General Observation - JOINTS IN PLACE THROUGHOUT REACH

All inspections of P24757Work order 0756080

Observations (8)

DistanceCodeObservation
2MGOOLD MAG COAT ON PIPE
0AMH4:15AM
0MWM—
506.9AMH4:55AM( ABANDONED MH)
506.7MGOJOINTS IN PLACE THROUGHOUT REACH
0MWL—
243.7MGORGRCP GOOD COND
12.7MGPOLD MAG COAT

Properties (6)

custom_field_three
48" RGRCP GOOD COND
custom_field_two
4
customer
LACSD
datetime
2019-06-12T03:59:04-07:00
documentation
MARTIN,REVELES,OLIVER 111,SHADLER
is_lateral_inspection
false
