Wastewater/Activity/PacpInspection/1.0Jun 11, 2019, 08:02 AM
B 1370_B 1369_6112019_011243.mp4
- Date
- 06/11/2019
- W/O
- 0771792
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z01126
- PipeID
- P25082
- Time
- 1:02 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1229
- Sewer Name
- B JOINT OUTFALL B - UNIT 6J
- City
- PASADENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 08
- Purpose
- Routine Assessment
- Project
- 20190610MDM_JOINT_OUTFALL_B_UNIT_6J
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Upstream MH
- B 1370
- Downstream MH
- B 1369
- Dir. of Survey
- Downstream
- Length Surveyed
- 168.8 ft.
- Total Length
- 168.8 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 3
Observation photos (3)
2 ft. - Lining Failure Blistered, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SMALL POPPING BLISTERS
8 ft. - General Observation - 18" VCP + CIPP
32.1 ft. - General Observation - ROUGH TEXTURE INSDE BLISTER
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 8 | MGO | 18" VCP + CIPP |
| 0 | MGO | Conn. @ Mh, 3 O' Clock. Active |
| 0 | AMH | 1:05AM |
| 16.7 | TB | Open |
| 168.1 | LFB | SMALL POPPING BLISTERS |
| 168.8 | AMH | 1:25AM |
| 0 | MWL | — |
| 157.6 | TB | Open |
| 0 | MWM | — |
| 121.1 | TB | Open |
| 32.1 | MGO | ROUGH TEXTURE INSDE BLISTER |
| 2 | LFB | SMALL POPPING BLISTERS |
Properties (7)
- custom_field_three
- CIPP LINER SMALL POPPING BLISTERS
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-06-11T01:02:38-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,SHADERER
- is_lateral_inspection
- false
- lining
- CIPP
