Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 16, 2018, 05:01 PM

  • 03 0474_C 0511_1162018_112248.mp4

Date
01/16/2018
W/O
PENDING
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00401
PipeID
P21638
Time
9:01 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7604
Sewer Name
03 PUMP DISTRICT #5 CONNECTION TRUNK
City
LONG BEACH
Loc. details
Other
Location Code
Z
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
22
Purpose
Routine Assessment
Project
20180116DF_PUMP_DISTRICT_5_CONNECTION_TR
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Upstream MH
03 0474
Downstream MH
C 0511
Dir. of Survey
Downstream
Length Surveyed
2.1 ft.
Total Length
2.1 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
5
O&M Quick
5100
O&M Rating
5
Overall Index
5
Overall Quick
—
Overall Rating
5
Pipe schematic from manhole 03 0474 to C 0511
MH: 03 0474MH: C 0511downstream0 ft. AMH - Upstream Manhole, Survey Begins - 11:22 AM0.1 ft. MWL - Water Level, 90 %of cross sectional area0.1 ft. MWM - Water Mark, 95 %of cross sectional area2.1 ft. MSA - Survey Abandoned - HIGH WATER

Observation photos (3)

  • Upstream Manhole, Survey Begins - 11:22 AM

    0 ft. - Upstream Manhole, Survey Begins - 11:22 AM

  • Water Level, 90 %of cross sectional area

    0.1 ft. - Water Level, 90 %of cross sectional area

  • Water Mark, 95 %of cross sectional area

    0.1 ft. - Water Mark, 95 %of cross sectional area

All inspections of P21638Work order PENDING

Observations (4)

DistanceCodeObservation
0.1MWL—
0AMH11:22 AM
2.1MSAHIGH WATER
0.1MWM—

Properties (5)

custom_field_two
5
customer
LACSD
datetime
2018-01-16T09:01:26-08:00
documentation
FRANKLIN, VENDRYES, BRAR
is_lateral_inspection
false
