Wastewater/Activity/PacpInspection/1.0Jun 5, 2019, 04:32 PM
Section#1_A 0100_A 1098__652019__I0152.mp4
- Date
- 06/05/2019
- W/O
- 0771914
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00339
- PipeID
- P21583
- Time
- 9:32 AM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- I0152
- Sewer Name
- A JOINT OUTFALL A - UNIT 8
- City
- LONG BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 04
- Purpose
- Capital Improvement Program Assesment
- Project
- 20190605DF_JOINT_OUTFALL_A_UNIT_8
- Material
- RCP-CTL
- Shape
- Circular
- Height
- 33 in.
- Upstream MH
- A 0100
- Downstream MH
- A 1098
- Dir. of Survey
- Downstream
- Length Surveyed
- 6.5 ft.
- Total Length
- 6.5 ft.
- Structural Index
- 3
- Structural Quick
- 3221
- Structural Rating
- 8
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (3)
0.1 ft. - Water Mark, 35 %of cross sectional area
2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES
Observations (8)
| Distance | Code | Observation |
|---|---|---|
| 6.5 | AMH | 9:59 AM |
| 2 | CM | — |
| 5.5 | CM | — |
| 0 | AMH | 9:35 AM |
| 2 | SSS | — |
| 6.5 | MGO | GREASE THROUGHOUT THE REACH 5% LESS |
| 0.1 | MWL | — |
| 0.1 | MWM | — |
Properties (5)
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2019-06-05T09:32:40-07:00
- documentation
- FRANKLIN, BRAR, CASTILLO
- is_lateral_inspection
- false
