Wastewater/Activity/PacpInspection/1.0Jun 5, 2019, 07:53 AM
B 0445_B 0444_652019_010818.mp4
- Date
- 06/05/2019
- W/O
- 0772196
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00093
- PipeID
- P08957
- Time
- 12:53 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1222
- Sewer Name
- B JOINT OUTFALL B - UNIT 5C
- City
- SIERRA MADRE
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 11
- Purpose
- Capital Improvement Program Assesment
- Project
- 20190603MDM_JOINT_OUTFALL_B_UNIT_5C
- Material
- NRCP
- Shape
- Circular
- Height
- 21 in.
- Upstream MH
- B 0445
- Downstream MH
- B 0444
- Dir. of Survey
- Downstream
- Length Surveyed
- 70.7 ft.
- Total Length
- 70.7 ft.
- Structural Index
- 3
- Structural Quick
- 4121
- Structural Rating
- 6
- O&M Index
- 4
- O&M Quick
- 4100
- O&M Rating
- 4
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 10
Observation photos (3)
0 ft. - General Observation - 60% MAG COAT START
2 ft. - Surface Aggregate Missing, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG
2 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - BLISTERING PEELING CONCRETE
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 55.7 | MGO | 60% MAG COAT FINISH |
| 2 | SAM | SEVERE AGG |
| 70.2 | SSS | BLISTERING PEELING CONCRETE |
| 70.2 | MGO | Conn. @ Mh, 9 O' Clock. Active |
| 0 | AMH | 12:55AM |
| 70.7 | AMH | 1;10AM |
| 55.7 | MWM | — |
| 0 | MGO | Conn. @ Mh, 9 O' Clock. Active |
| 0 | MWM | — |
| 0 | MWL | — |
| 0 | MGO | 60% MAG COAT START |
| 2 | SSS | BLISTERING PEELING CONCRETE |
| 55.7 | MWL | — |
| 70.2 | SAM | SEVERE AGG |
Properties (6)
- custom_field_three
- SEVERE AGG MISSING
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2019-06-05T00:53:36-07:00
- documentation
- MARTIN,REVELES,OLIVER 111
- is_lateral_inspection
- false
