Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 3, 2019, 10:25 AM

  • B 0447_B 0446_632019_033032.mp4

Date
06/03/2019
W/O
0772196
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00093
PipeID
P08959
Time
3:25 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1220
Sewer Name
B JOINT OUTFALL B - UNIT 5C
City
SIERRA MADRE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
11
Purpose
Capital Improvement Program Assesment
Project
20190603MDM_JOINT_OUTFALL_B_UNIT_5C
Material
NRCP
Shape
Circular
Height
21 in.
Upstream MH
B 0447
Downstream MH
B 0446
Dir. of Survey
Downstream
Length Surveyed
128.9 ft.
Total Length
128.9 ft.
Structural Index
3
Structural Quick
4221
Structural Rating
10
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
10
Pipe schematic from manhole B 0447 to B 0446
MH: B 0447MH: B 0446downstream0 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Capped0 ft. AMH - Upstream Manhole, Survey Begins - 3:25AM0 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Capped2 ft. SAM - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG2 ft. MGO - General Observation - 85% MAG COAT START2 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - PEELING CONCRETE SEVERE AGG ATTACHED87.6 ft. SAM - Surface Aggregate Missing, from 09 to 12 o'clock, within 8 inches of joint: NO - SEVERE AGG128.6 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish - PEELING CONCRETE SEVERE AGG ATTACHED128.6 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active128.6 ft. MGO - General Observation - 85% MAG COAT FINISH128.6 ft. SAM - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish - SEVERE AGG128.9 ft. AMH - Downstream Manhole, Survey Ends - 3:35AM

Observation photos (4)

  • Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG

    2 ft. - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG

  • General Observation - 85% MAG COAT START

    2 ft. - General Observation - 85% MAG COAT START

  • Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - PEELING CONCRETE SEVERE AGG ATTACHED

    2 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - PEELING CONCRETE SEVERE AGG ATTACHED

  • Surface Aggregate Missing, from 09 to 12 o'clock, within 8 inches of joint: NO - SEVERE AGG

    87.6 ft. - Surface Aggregate Missing, from 09 to 12 o'clock, within 8 inches of joint: NO - SEVERE AGG

All inspections of P08959Work order 0772196

Observations (12)

DistanceCodeObservation
128.6SSSPEELING CONCRETE SEVERE AGG ATTACHED
128.6MGOConn. @ Mh, 9 O' Clock. Active
128.9AMH3:35AM
2SAMSEVERE AGG
128.6MGO85% MAG COAT FINISH
0MGOConn. @ Mh, 3 O' Clock. Capped
87.6SAMSEVERE AGG
2MGO85% MAG COAT START
0AMH3:25AM
2SSSPEELING CONCRETE SEVERE AGG ATTACHED
0MGOConn. @ Mh, 9 O' Clock. Capped
128.6SAMSEVERE AGG

Properties (6)

custom_field_three
PEELING CONCRETE SEVERE AGG ATTACHED- 85% MAG COAT
custom_field_two
2
customer
LACSD
datetime
2019-06-03T03:25:00-07:00
documentation
MARTIN,REVELES,OLIVER 111
is_lateral_inspection
false
