Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 3, 2019, 08:45 AM

  • B 0450_B 0499_632019_015338.mp4

Date
06/03/2019
W/O
0772196
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00093
PipeID
P08962
Time
1:45 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1220
Sewer Name
B JOINT OUTFALL B - UNIT 5C
City
SIERRA MADRE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
11
Purpose
Capital Improvement Program Assesment
Project
20190603MDM_JOINT_OUTFALL_B_UNIT_5C
Material
NRCP
Shape
Circular
Height
21 in.
Upstream MH
B 0450
Downstream MH
B 0449
Dir. of Survey
Downstream
Length Surveyed
231.7 ft.
Total Length
231.7 ft.
Structural Index
3
Structural Quick
4222
Structural Rating
12
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
12
Pipe schematic from manhole B 0450 to B 0449
MH: B 0450MH: B 0449downstream0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:45AM0 ft. MWM - Water Mark, 40 %of cross sectional area2 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - PEELING CONCRETE SEVERE AGG ATTACHED2 ft. SAM - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG2 ft. MGO - General Observation - MAG COAT 85% START10.2 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO - PEELING CONCRETE SEVERE AGG ATTACHED18.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open59.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped63.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - OPEN123.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open126.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped146.8 ft. SAM - Surface Aggregate Missing, from 12 to 03 o'clock, within 8 inches of joint: NO - SEVERE AGG185.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped189.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open231.3 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish - PEELING CONCRETE SEVERE AGG ATTACHED231.3 ft. SAM - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish - SEVERE AGG231.3 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. OPEN231.3 ft. MGO - General Observation - MAG COAT 85% FINISH231.7 ft. AMH - Downstream Manhole, Survey Ends - 2:10AM

Observation photos (5)

  • Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - PEELING CONCRETE SEVERE AGG ATTACHED

    2 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - PEELING CONCRETE SEVERE AGG ATTACHED

  • Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG

    2 ft. - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG

  • General Observation - MAG COAT 85% START

    2 ft. - General Observation - MAG COAT 85% START

  • Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO - PEELING CONCRETE SEVERE AGG ATTACHED

    10.2 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO - PEELING CONCRETE SEVERE AGG ATTACHED

  • Surface Aggregate Missing, from 12 to 03 o'clock, within 8 inches of joint: NO - SEVERE AGG

    146.8 ft. - Surface Aggregate Missing, from 12 to 03 o'clock, within 8 inches of joint: NO - SEVERE AGG

All inspections of P08962Work order 0772196

Observations (20)

DistanceCodeObservation
10.2SSSPEELING CONCRETE SEVERE AGG ATTACHED
189.1TFOpen
231.3SSSPEELING CONCRETE SEVERE AGG ATTACHED
126.1TFCCapped
18.1TFOpen
2SSSPEELING CONCRETE SEVERE AGG ATTACHED
146.8SAMSEVERE AGG
185.7TFCCapped
59.6TFCCapped
2SAMSEVERE AGG
63.3TFOPEN
231.7AMH2:10AM
0MWL—
231.3SAMSEVERE AGG
123.2TFOpen
0AMH1:45AM
231.3MGOConn. @ Mh, 9 O' Clock. OPEN
2MGOMAG COAT 85% START
231.3MGOMAG COAT 85% FINISH
0MWM—

Properties (6)

custom_field_three
PEELING CONCRETE SEVERE AGG ATTACHED-85% MAG COAT
custom_field_two
2
customer
LACSD
datetime
2019-06-03T01:45:00-07:00
documentation
MARTIN,REVELES,OLIVER 111
is_lateral_inspection
false
