Wastewater/Activity/PacpInspection/1.0Mar 6, 2019, 06:34 AM
21 0387_21 0386 _03052019_233948.mp4
- Date
- 03/05/2019
- W/O
- 752349
- Weather
- Dry
- Operator/Surveyor
- J. BUENROSTRO
- Sewer ID
- Z00757
- PipeID
- P20185
- Time
- 10:34 PM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K5821
- Sewer Name
- 21 CENTER STREET TRUNK
- City
- CITY OF INDUSTRY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 21
- Page No.
- 35
- Purpose
- Routine Assessment
- Project
- WO_752349_TV21069_FEB2019
- Sewer Type
- Siphon
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 21 0386
- Downstream MH
- 21 0387
- Dir. of Survey
- Upstream
- Length Surveyed
- 2.1 ft.
- Total Length
- 2.1 ft.
- Structural Index
- 2
- Structural Quick
- 2111
- Structural Rating
- 3
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 3
Observation photos (2)
2.1 ft. - Crack Circumferential, from 10 to 02 o'clock, within 8 inches of joint: NO
2.1 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES
Observations (7)
| Distance | Code | Observation |
|---|---|---|
| 2.1 | CC | — |
| 0 | MWL | — |
| 2.1 | MSA | VIEW OF THE SIPHON UPLEG FROM D/S MH |
| 0 | AMH | 21 0386 |
| 2.1 | SSS | — |
| 0 | MGO | WEST BARREL |
| 0 | MWM | — |
Properties (6)
- additional_info
- SC366397
- custom_field_two
- 5
- customer
- LACSD
- datetime
- 2019-03-05T22:34:58-08:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
