Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 4, 2019, 09:37 AM

  • 05 0725_05 0724_03042019_025427.mp4

Date
03/04/2019
W/O
750840
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00521
PipeID
P05948
Time
1:37 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6413
Sewer Name
05 SOUTH INGLEWOOD-ORANGE AVENUE TRUNK, EXTENSION #1
City
INGLEWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
07
Purpose
Routine Assessment
Project
RFIR_WO_750840_TV05333_FEB2019
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Width
8 in.
Upstream MH
05 0725
Downstream MH
05 0724
Dir. of Survey
Downstream
Length Surveyed
354.1 ft.
Total Length
354.1 ft.
Structural Index
3
Structural Quick
4E3G
Structural Rating
246
O&M Index
2
O&M Quick
2M00
O&M Rating
140
Overall Index
3
Overall Quick
—
Overall Rating
386
Pipe schematic from manhole 05 0725 to 05 0724
MH: 05 0725MH: 05 0724downstream0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 05 07250 ft. MGO - General Observation - COCKROACHES IN MANHOLE0 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 9 O'CLOCK0 ft. MWL - Water Level, 10 %of cross sectional area2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start11.3 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start12.7 ft. TFA - Tap Factory Made Active, at 03 o'clock, -, within 8 inches of joint: NO, 6"60 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: NO, 6", 69"66.1 ft. TFC - Tap Factory Made Capped, at 03 o'clock, -, within 8 inches of joint: NO, 6"105.9 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"113.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"167.2 ft. TFC - Tap Factory Made Capped, at 03 o'clock, -, within 8 inches of joint: NO, 6"194.7 ft. FM - Fracture Multiple, from 12 to 12 o'clock, within 8 inches of joint: YES195.4 ft. TBA - Tap Break-In Active, at 11 o'clock, -, within 8 inches of joint: YES, 6"205.9 ft. TFC - Tap Factory Made Capped, at 03 o'clock, -, within 8 inches of joint: NO, 6"207.6 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish207.6 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start283.6 ft. MWLS - Water Level, Sag in pipe, 50 %of cross sectional area, Start283.6 ft. TFA - Tap Factory Made Active, at 03 o'clock, -, within 8 inches of joint: NO, 6"297.4 ft. MWLS - Water Level, Sag in pipe, 50 %of cross sectional area, Finish350.5 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish353.6 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish354.1 ft. AMH - Downstream Manhole, Survey Ends - 05 0724

Observation photos (6)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    11.3 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Fracture Multiple, from 12 to 12 o'clock, within 8 inches of joint: YES

    194.7 ft. - Fracture Multiple, from 12 to 12 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    207.6 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Water Level, Sag in pipe, 50 %of cross sectional area, Start

    283.6 ft. - Water Level, Sag in pipe, 50 %of cross sectional area, Start

All inspections of P05948Work order 750840

Observations (24)

DistanceCodeObservation
354.1AMH05 0724
350.5FM—
2DAGS—
66.1TFC—
207.6CM—
12.7TFA—
0MWM—
205.9TFC—
195.4TBA—
60TBA—
113.5TFC—
0AMH05 0725
0MGOCOCKROACHES IN MANHOLE
297.4MWLS—
11.3CM—
0MGOACTIVE CONNECTION AT MH 9 O'CLOCK
283.6MWLS—
167.2TFC—
194.7FM—
283.6TFA—
207.6FM—
353.6DAGS—
105.9TBA—
0MWL—

Properties (6)

additional_info
SC365929
custom_field_two
2
customer
LACSD
datetime
2019-03-04T01:37:48-08:00
documentation
PRO PIPE
is_lateral_inspection
false
