Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 27, 2018, 07:57 AM

  • 15 0610_15 0609A _09272018_010104.mp4

Date
09/27/2018
W/O
729689
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00601
PipeID
P12544
Time
12:57 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6047
Sewer Name
15 DOUBLE AVENUE TRUNK
City
EL MONTE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
11
Purpose
Routine Assessment
Project
RFIR_WO_729689_TV15205_OCT2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
15 0609A
Downstream MH
15 0610
Dir. of Survey
Upstream
Length Surveyed
226.5 ft.
Total Length
226.5 ft.
Structural Index
3
Structural Quick
3M00
Structural Rating
213
O&M Index
2
O&M Quick
2H00
O&M Rating
90
Overall Index
3
Overall Quick
—
Overall Rating
303
Pipe schematic from manhole 15 0609A to 15 0610
MH: 15 0609AMH: 15 0610upstream0 ft. AMH - Upstream Manhole, Survey Ends - 15 06101.2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish1.2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish1.2 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish65 ft. TFA - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: NO, 6"92.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"124 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start136.5 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES148.9 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"169.1 ft. CM - Crack Multiple, from 10 to 11 o'clock, within 8 inches of joint: YES182.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"221.1 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start224.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start226.5 ft. MWL - Water Level, 5 %of cross sectional area226.5 ft. AMH - Downstream Manhole, Survey Begins - 15 0609A226.5 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 3 O'CLOCK226.5 ft. MWM - Water Mark, 20 %of cross sectional area

Observation photos (5)

  • Deposits Attached Grease, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    5.4 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Crack Multiple, from 10 to 11 o'clock, within 8 inches of joint: YES

    57.4 ft. - Crack Multiple, from 10 to 11 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    90 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    102.5 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P12544Work order 729689

Observations (17)

DistanceCodeObservation
43.7TFC—
102.5CM—
225.3DAGS—
225.3CM—
57.4CM—
0MWL—
225.3SAP—
77.6TFA—
134.1TFC—
5.4SAP—
161.5TFA—
90CM—
0AMH15 0609A
2DAGS—
0MGOACTIVE CONNECTION AT MH 3 O'CLOCK
226.5AMH15 0610
0MWM—

Properties (5)

additional_info
SC365110
custom_field_two
2
customer
LACSD
datetime
2018-09-27T00:57:22-07:00
is_lateral_inspection
false
