Wastewater/Activity/PacpInspection/1.0May 30, 2019, 10:52 AM
B 1274_B 1273_5302019_041047.mp4
- Date
- 05/30/2019
- W/O
- 0771915
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z01126
- PipeID
- P25169
- Time
- 3:52 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1219
- Sewer Name
- B JOINT OUTFALL B - UNIT 6J
- City
- PASADENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 12
- Purpose
- Capital Improvement Program Assesment
- Project
- 201905MDM_JOINT_OUTFALL_B_UNIT_6J
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 24 in.
- Upstream MH
- B 1274
- Downstream MH
- B 1273
- Dir. of Survey
- Downstream
- Length Surveyed
- 169.7 ft.
- Total Length
- 169.7 ft.
- Structural Index
- 4
- Structural Quick
- 4200
- Structural Rating
- 8
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 10
Observation photos (4)
2 ft. - General Observation - 80% MAG COAT START
2 ft. - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG
109.6 ft. - Surface Aggregate Missing, from 09 to 03 o'clock, within 8 inches of joint: NO - SEVERE AGG
131.8 ft. - Deposits Settled Other, 10 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: NO - ROCKS DEBRIE
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 169.3 | MGO | 80% MAG COAT FINISH |
| 2 | MGO | 80% MAG COAT START |
| 2 | SAM | SEVERE AGG |
| 169.3 | SAM | SEVERE AGG |
| 0 | MWM | — |
| 0 | MWL | — |
| 169.7 | AMH | 4:30AM |
| 0 | AMH | 4:15AM |
| 109.6 | SAM | SEVERE AGG |
| 131.8 | DSZ | ROCKS DEBRIE |
Properties (6)
- custom_field_three
- SEVERE AGG MISSING-80% MAG COAT
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2019-05-30T03:52:39-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,RUVALCABA
- is_lateral_inspection
- false
