Wastewater/Activity/PacpInspection/1.0May 24, 2019, 06:03 PM
B 0457_B 0456_5242019_110438.mp4
- Date
- 05/24/2019
- W/O
- 0773144
- Weather
- Dry
- Operator/Surveyor
- SANTIAGO OBREGON
- Sewer ID
- Z00093
- PipeID
- P20279
- Time
- 11:03 AM
- Certificate
- U-1014-06022541
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7987
- Sewer Name
- B JOINT OUTFALL B - UNIT 5C
- City
- PASADENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 11
- Purpose
- Maintenance Related
- Project
- 20190524SHO_JOINT_OUTFALL_B_UNIT_5C
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 24 in.
- Upstream MH
- B 0457
- Downstream MH
- B 0456
- Dir. of Survey
- Downstream
- Length Surveyed
- 36.4 ft.
- Total Length
- 36.4 ft.
- Structural Index
- 2
- Structural Quick
- 2100
- Structural Rating
- 2
- O&M Index
- 5
- O&M Quick
- 5100
- O&M Rating
- 5
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 7
Observation photos (2)
36.4 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES
36.4 ft. - Deposits Settled Other, 40 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES - SPALLING/SHAVINGS
Observations (4)
| Distance | Code | Observation |
|---|---|---|
| 36.4 | SSS | — |
| 36.4 | MSA | TURN IN THE AIRLINE |
| 0 | AMH | AIRLINE INSPECTION ONLY |
| 36.4 | DSZ | SPALLING/SHAVINGS |
Properties (5)
- additional_info
- AIRLINE INSPECTION ONLY
- customer
- LACSD
- datetime
- 2019-05-24T11:03:54-07:00
- documentation
- OBREGON, YOUNG, IGNACIO, CASTILLO
- is_lateral_inspection
- false
