Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 14, 2019, 08:33 AM

  • C 0552_A 0832_03142019_014047.mp4

Date
03/14/2019
W/O
756635
Weather
Dry
Operator/Surveyor
J. BUENROSTRO
Sewer ID
Z00362
PipeID
P05251
Time
1:33 AM
Certificate
U-715-07000770
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K5828
Sewer Name
C JOINT OUTFALL C - UNIT 4D
City
LONG BEACH
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
12
Purpose
Routine Assessment
Project
WO_756635_TV03085_MAR2019
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
30 in.
Width
30 in.
Upstream MH
C 0552
Downstream MH
A 0832
Dir. of Survey
Downstream
Length Surveyed
80.7 ft.
Total Length
80.7 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
3
O&M Quick
4121
O&M Rating
6
Overall Index
3
Overall Quick
—
Overall Rating
6
Pipe schematic from manhole C 0552 to A 0832
MH: C 0552MH: A 0832downstream0 ft. MWL - Water Level, 25 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - C 05520 ft. MGO - General Observation - SERVICE CONNECTION AT 3 O' CLOCK AT MH0 ft. MWM - Water Mark, 50 %of cross sectional area3.2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start3.2 ft. MGO - General Observation - LINER76.3 ft. MGO - General Observation - MH LINER DETATCHED76.3 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish80.7 ft. MGO - General Observation - CONNECTIONS AT BOTH 3 AND 9 O' CLOCK AT MH80.7 ft. AMH - Downstream Manhole, Survey Ends - A 0832

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    3.2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • General Observation - MH LINER DETATCHED

    76.3 ft. - General Observation - MH LINER DETATCHED

All inspections of P05251Work order 756635

Observations (10)

DistanceCodeObservation
0MWL—
0AMHC 0552
76.3MGOMH LINER DETATCHED
3.2DAGS—
76.3DAGS—
0MGOSERVICE CONNECTION AT 3 O' CLOCK AT MH
3.2MGOLINER
0MWM—
80.7MGOCONNECTIONS AT BOTH 3 AND 9 O' CLOCK AT MH
80.7AMHA 0832

Properties (8)

additional_info
SC366058
custom_field_two
4
customer
LACSD
datetime
2019-03-14T01:33:50-07:00
documentation
PROPIPE
is_lateral_inspection
false
lining
CIPP
year_laid
36286
