Wastewater/Activity/PacpInspection/1.0Dec 31, 2018, 11:14 AM
D 0119_D 0118 _12312018_034517.mp4
- Date
- 12/31/2018
- W/O
- 740289
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00156
- PipeID
- P10028
- Time
- 3:14 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K6307
- Sewer Name
- D JOINT OUTFALL D - UNIT 6
- City
- REDONDO BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 16
- Purpose
- Routine Assessment
- Project
- RFIR_WO_740259_TV05172_DEC2018
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 33 in.
- Width
- 33 in.
- Upstream MH
- D 0119
- Downstream MH
- D 0118
- Dir. of Survey
- Downstream
- Length Surveyed
- 373.9 ft.
- Total Length
- 373.9 ft.
- Structural Index
- 3
- Structural Quick
- 5A3N
- Structural Rating
- 282
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 282
Observation photos (4)
2.1 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
136.3 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
204.7 ft. - Surface Reinforcement Visible, from 10 to 02 o'clock, within 8 inches of joint: YES
318.2 ft. - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 371 | SRV | — |
| 0 | MWL | — |
| 136.3 | SAP | — |
| 0 | MWM | — |
| 136.3 | SAV | — |
| 2.1 | MGO | MAG COAT |
| 204.7 | SRV | — |
| 318.2 | SRV | — |
| 372.3 | SAP | — |
| 373.9 | AMH | D 0118 |
| 373.9 | MGO | CONNECTION AT MH 3 O'CLOCK |
| 2.1 | SAV | — |
| 0 | AMH | D 0119 |
Properties (6)
- additional_info
- SC365491
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2018-12-31T03:14:10-08:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
