Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 20, 2019, 04:00 PM

  • C 0177A_C 0177_5202019_092703.mp4

Date
05/20/2019
W/O
0766542
Weather
Dry
Operator/Surveyor
BRAR
Sewer ID
Z00130
PipeID
P09702
Time
9:00 AM
Certificate
SEE REMARKS
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7983
Sewer Name
C JOINT OUTFALL C - UNIT 5C
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 19
Page No.
10
Purpose
Routine Assessment
Project
20190520SB_JOINT_OUTFALL_C_UNIT_5C
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Upstream MH
C 0177A
Downstream MH
C 0177
Dir. of Survey
Downstream
Length Surveyed
279.6 ft.
Total Length
279.6 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole C 0177A to C 0177
MH: C 0177AMH: C 0177downstream0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 9:06 AM0.1 ft. MWM - Water Mark, 10 %of cross sectional area2 ft. SZ - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - MAG PRESENT 100%16.9 ft. MGP - General Photograph81.3 ft. MGP - General Photograph152.6 ft. MGP - General Photograph225.5 ft. MGP - General Photograph276.1 ft. SZ - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - MAG PRESENT 100%, SLIGHT OVERSPRAY AT BOTTOM279.6 ft. AMH - Downstream Manhole, Survey Ends - 10:02 AM

Observation photos (5)

  • Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - MAG PRESENT 100%

    2 ft. - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - MAG PRESENT 100%

  • General Photograph

    16.9 ft. - General Photograph

  • General Photograph

    81.3 ft. - General Photograph

  • General Photograph

    152.6 ft. - General Photograph

  • General Photograph

    225.5 ft. - General Photograph

All inspections of P09702Work order 0766542

Observations (10)

DistanceCodeObservation
16.9MGP—
225.5MGP—
0.1MWM—
2SZMAG PRESENT 100%
276.1SZMAG PRESENT 100%, SLIGHT OVERSPRAY AT BOTTOM
0MWL—
81.3MGP—
0AMH9:06 AM
279.6AMH10:02 AM
152.6MGP—

Properties (6)

additional_info
U-0618-0703002249
custom_field_two
4
customer
LACSD
datetime
2019-05-20T09:00:24-07:00
documentation
BRAR, FRANKLIN, CASTILLO
is_lateral_inspection
false
