Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 20, 2018, 05:47 AM

  • 05 0098_05 0097 _12192018_222339.mp4

Date
12/19/2018
W/O
740131
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00431
PipeID
P05388
Time
9:47 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6253
Sewer Name
05 DISTRICT #5 MAIN TRUNK
City
HAWTHRONE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
17
Purpose
Routine Assessment
Project
RFIR_WO_740015_TV05147_DEC2018
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
42 in.
Width
42 in.
Upstream MH
05 0098
Downstream MH
05 0097
Dir. of Survey
Downstream
Length Surveyed
335.8 ft.
Total Length
335.8 ft.
Structural Index
3
Structural Quick
513L
Structural Rating
206
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
206
Pipe schematic from manhole 05 0098 to 05 0097
MH: 05 0098MH: 05 0097downstream0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. MWL - Water Level, 25 %of cross sectional area0 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Begins - 05 00982.8 ft. MGO - General Observation - MAG COAT2.8 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start308 ft. SRV - Surface Reinforcement Visible, from 09 to 10 o'clock, within 8 inches of joint: NO335.8 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish335.8 ft. AMH - Downstream Manhole, Survey Ends - 05 0097

Observation photos (2)

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2.8 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Reinforcement Visible, from 09 to 10 o'clock, within 8 inches of joint: NO

    308 ft. - Surface Reinforcement Visible, from 09 to 10 o'clock, within 8 inches of joint: NO

All inspections of P05388Work order 740131

Observations (10)

DistanceCodeObservation
335.8SAP—
0MGOCONNECTION AT MH 9 O'CLOCK
0MWL—
0MWM—
2.8MGOMAG COAT
308SRV—
335.8AMH05 0097
2.8SAP—
0MGOCONNECTION AT MH 3 O'CLOCK
0AMH05 0098

Properties (5)

additional_info
SC365486
custom_field_two
2
customer
LACSD
datetime
2018-12-19T21:47:36-08:00
is_lateral_inspection
false
