Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 30, 2019, 06:14 AM

  • 18 0464_18 0463_01292019_222521.mp4

Date
01/29/2019
W/O
745525
Weather
Dry
Operator/Surveyor
E.RUIZ
Sewer ID
Z00691
PipeID
P14318
Time
10:14 PM
Certificate
U-715-07000753
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K6372
Sewer Name
18 NORTH PLANT OUTFALL TRUNK
City
WHITTIER
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
20
Purpose
Routine Assessment
Project
WO_18099_TV745525_JAN2019
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Width
24 in.
Upstream MH
18 0464
Downstream MH
18 0463
Dir. of Survey
Downstream
Length Surveyed
120.1 ft.
Total Length
120.1 ft.
Structural Index
4
Structural Quick
4C32
Structural Rating
94
O&M Index
3
O&M Quick
4111
O&M Rating
5
Overall Index
4
Overall Quick
—
Overall Rating
99
Pipe schematic from manhole 18 0464 to 18 0463
MH: 18 0464MH: 18 0463downstream0 ft. MWM - Water Mark, 55 %of cross sectional area0 ft. MWL - Water Level, 55 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 18 04644.5 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES7 ft. FM - Fracture Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Start56.9 ft. RFJ - Roots Fine Joint, at 01 o'clock, within 8 inches of joint: YES97.3 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 8"117.7 ft. FM - Fracture Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Finish117.7 ft. MMC - Material Change, Reinforced concrete pipe117.7 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES120.1 ft. MGO - General Observation - CONNECTION AT MH 3 OCLOCK120.1 ft. AMH - Downstream Manhole, Survey Ends - 18 0463

Observation photos (2)

  • Fracture Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Start

    7 ft. - Fracture Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES

    117.7 ft. - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES

All inspections of P14318Work order 745525

Observations (12)

DistanceCodeObservation
97.3TB—
0MWM—
120.1MGOCONNECTION AT MH 3 OCLOCK
4.5FL—
120.1AMH18 0463
117.7FM—
0MWL—
117.7MMC—
7FM—
0AMH18 0464
117.7SAP—
56.9RFJ—

Properties (4)

custom_field_two
2
customer
LACSD
datetime
2019-01-29T22:14:54-08:00
is_lateral_inspection
false
