Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 4, 2019, 06:56 AM

  • 01 0526_01 0525_01032019_231529.mp4

Date
01/03/2019
W/O
740024
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00206
PipeID
P01011
Time
10:56 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K6313
Sewer Name
01 CROCKETT BOULEVARD-GLEN AVENUE TRUNK
City
LOS ANGELES
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
10
Purpose
Routine Assessment
Project
RFIR_WO_740024_TV01017_DEC2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
01 0526
Downstream MH
01 0525
Dir. of Survey
Downstream
Length Surveyed
309.2 ft.
Total Length
309.2 ft.
Structural Index
3
Structural Quick
423K
Structural Rating
190
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
190
Pipe schematic from manhole 01 0526 to 01 0525
MH: 01 0526MH: 01 0525downstream0 ft. MWL - Water Level, 25 %of cross sectional area0 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01 05263.2 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES10.1 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES16.2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start32.6 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"35.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"83 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"85.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"130.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"132.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"180.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"183.5 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"185.6 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES195.2 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES232.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"235.2 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"282.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"285.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"288.1 ft. MGO - General Observation - ABANDONED MH309.1 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish309.2 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK309.2 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK309.2 ft. AMH - Downstream Manhole, Survey Ends - 01 0525

Observation photos (6)

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    3.2 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    10.1 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    16.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES

    185.6 ft. - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    195.2 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • General Observation - ABANDONED MH

    288.1 ft. - General Observation - ABANDONED MH

All inspections of P01011Work order 740024

Observations (25)

DistanceCodeObservation
309.2MGOCONNECTION AT MH 3 O'CLOCK
85.6TFC—
130.1TFC—
185.6FL—
35.1TFC—
83TFC—
0MWL—
10.1CL—
309.2MGOCONNECTION AT MH 9 O'CLOCK
16.2CM—
195.2FM—
288.1MGOABANDONED MH
180.9TFC—
232.2TFC—
0MWM—
0AMH01 0526
285.3TFC—
132.8TFC—
32.6TFC—
3.2FM—
235.2TF—
309.1CM—
309.2AMH01 0525
183.5TFC—
282.8TF—

Properties (5)

additional_info
SC365497
custom_field_two
3
customer
LACSD
datetime
2019-01-03T22:56:58-08:00
is_lateral_inspection
false
